  • Page 1 Alarm Communicator GS2060-SM GPRS Cellular Communicator TL260-SM Ethernet/Internet Communicator TL260GS-SM Ethernet/Internet and GPRS Dual-Path Communicator v2.0 Installation Manual Warning: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS GENERAL ................. . . 3 Panel Mounting .
  • Page 4 WARNING Please Read Carefully Note to Installers This Warning contains vital information. As the only individual in contact with system users, it is the installer’s responsibility to bring each item in this Warning to the attention of all users of this system. System Failures Motion Detectors This system has been carefully designed to be as effective as...

  • Page 5: General

    Do not touch the external antenna. Model Information GS2060-SM: Is a GPRS Cellular alarm Communicator that sends alarm communication to Sur-Gard System I, II, III (SG-DRL3IP), and IV (SG-DRL4IP) central station receivers via a GPRS digital cellular network. TL260-SM: Is an Ethernet only alarm Communicator that sends alarm communication to Sur-Gard System I, II, and III central station receivers through a wired Ethernet/Internet connection.

  • Page 6: Ul/Ulc Installation Requirements

    GSM or Ethernet or as a back-up in conjunction with the Digital Alarm Communicator Transmitter (DACT). Test transmission every 24 hours shall be enabled on each channel. • For ULC Commercial Fire and Burglary applications the GS2060-SM and TL260GS-SM can be used as a passive communication module with the following Security Levels: •...

  • Page 7: Pre Installation Configuration

    Communicator Description Panel • Sur-Gard System I Receiver, version 1.30+ • Sur-Gard System II Receiver, version 2.10+ GS2060-SM Receiver • Sur-Gard SG-DRL3-IP, version 2.30+ (for Sur-Gard System III Receiver) • Sur-Gard SG-DRL4-IP version 1.20+ (for Sur-Gard System IV Receiver) TL260-SM •...

  • Page 8: Installing The Ethernet Cable

    5. Securely fasten the RX- wire on the terminal block. 6. Securely fasten the GND wire on the terminal block . NOTE: The GND connection is optional, DSC recommends connecting the GND terminal at both ends. 7. Run the RS-422 Cable from the iHub to the Panel.
  • Page 9 (finger tight), attach the supplied 5” white quad band (screw) whip antenna to the threaded antenna connection PC1616/1832/1864 point at top of the panel. WARNING! GS2060-SM/TL260-SM/TL260GS-SM MODULES ARE POWER LIMITED O NOT ROUTE ANY . (25.4 WIRING OVER THE CIRCUIT BOARD AINTAIN AT LEAST SEPARATION BETWEEN ¼...
  • Page 10 3. Securely fasten the RX+ wire to TX+ on the terminal block. 4. Securely fasten the RX- wire to TX- on the terminal block. 5. Securely fasten the GND wire on the terminal block . NOTE: The GND connection is optional, DSC recommends connecting GND at both ends of cable.

  • Page 11: Initial Panel Programming

    Communicator Placement Test). Correct trouble indicated by flashes on yellow LED before continuing. (See Table 5 for troubleshooting assistance). 7. GS2060-SM/TL260GS-SM only: Perform the Communicator Placement Test on page 10. 8. Mount the Panel in final location indicated by placement test.

  • Page 12: Communicator Placement Test

    • T-LINK Network Fault/Restore: This log will occur for the following trouble conditions: SIM Lock Trouble, GSM Trouble, Ethernet Trouble, or Connect24 Configuration Trouble. • T-LINK Receiver Trouble/Restore: This log will occur for the following trouble conditions: Receiver Not Available Trouble, Receiver Supervision Trouble, or Failure to Communicate (FTC) Trouble. •...

  • Page 13: Red Network Connection Status Led

    SIM Lock Trouble (4 Flashes) This trouble will signify that the SIM lock feature has been enabled and the unit has not been programmed with the correct PIN for the SIM card. GSM Trouble (5 Flashes) This trouble is indicated for any of the following 4 conditions: 1.

  • Page 14: Communicator Reset / Update

    Network Activity LEDs (Red and Green) (TL260GS-SM only) • Ethernet Activity: Red LED will blink quickly once for Ethernet Transmit, or twice for Ethernet Receive. • GPRS Activity: Green LED 2 will blink quickly once for GPRS Transmit, or twice for GPRS Receive. Network Link LED (Yellow) (TL260-SM only) See Figure 3 for location of LED.

  • Page 15: Appendix A: Communicator Troubleshooting

    APPENDIX A: COMMUNICATOR TROUBLESHOOTING Table 5: Trouble LED indications Trouble Possible Trouble Possible Solution indication Causes • Check the power connections between the Panel and the Communicator. No Indication No Power • Confirm PC-LINK cable is properly installed between communicator and panel. •...

  • Page 16: Communicator Programming Sections

    COMMUNICATOR PROGRAMMING SECTIONS The Programming Sections in this document are accessed via panel Section for Ethernet/GPRS Programming. Enter: [*][8][installer code][851][# ##], Where # ## is the 3 digit Section number referenced in this document. The Programming Worksheets at the end of this document can be used to record the new values when pro- gramming changes have been made from the default values.
  • Page 17 [8] GSM Low Signal Trouble. Default (OFF). [006] System Toggle Options 2 [1] Ethernet 1 Receiver Enabled. Default (ON) (OFF for GS2060-SM). ON: Ethernet Receiver 1 is enabled. OFF: Ethernet Receiver 1 is disabled.

  • Page 18: Programming Options

    [008] DNS Server IP 2  Programming this Section is not permitted on a UL/ULC listed system. Default (000.000.000.000) Enter the IP address for DNS Server 2. Format is 4 fields, each field is a 3 digit decimal. Valid range: 000-255. NOTE: If no value is programmed and DHCP is used, the DHCP Server will assign this value.
  • Page 19 Table 7: Time Zone Offset (Continued) Offset Offset Location Location Hours Abbrev Hours Abbrev Eastern Standard Time AWST Australian Western Standard Time COT Colombia Time China Standard Time Ecuador Time HKST Hong Kong Standard Time Peru Time WITA Waktu Indonesia Bagian Tengah Acre Time TWT Taiwan Time -4.5...

  • Page 20: Communications Reporting Codes

    Table 7: Time Zone Offset (Continued) Offset Offset Location Location Hours Abbrev Hours Abbrev CAST Chinese Atlantic Standard Time WKST West Kazakhstan Standard Time Pakistan Time YEKT Yekaterinburg Time Uzbekistan Time Turkmenistan Time Reserved 70 - FF Tajikistan Time French Southern and Antarctic Time MVT Maldives Time MAWT Mawson Time Kyrgyzstan Time...

  • Page 21: Ethernet Receiver 1 Options

    Alternate Test Transmission: Alternate Test Transmission can be enabled or disabled in Section [005] Toggle Option [7]. [026] Ethernet 1 Transmission Default (FF) Program 00 to disable this event transmission or FF to enable. See System Test Options (above) for details on settings. [027] Ethernet 2 Transmission Default (00) Program 00 to disable this event transmission or FF to enable.

  • Page 22: Ethernet Receiver 2 Options

    [105] Ethernet Receiver 1 Local Port Default (0BF4/3060) Use this Section to set the value of the local outgoing port. Set the value of this port when your installation is located behind a firewall and must be assigned a particular port number as determined by your central station system administrator.

  • Page 23: Gprs Receiver 1 Options

    GPRS Receiver 1 Options [201] GPRS Receiver 1 Account Code Default (0000000000) The account code is used by the central station to distinguish between transmitters. This account code is used when transmitting heartbeat signals to the central station receiver. Signals received from the control panel will use the control panel account number.

  • Page 24: Gprs Options

    GPRS Options [221] GPRS Public Access Point Name Default ( ) When the Communicator is operating on a private APN, use this Section to select a public APN for DLS and Remote Firmware Update. This information is available from your network carrier. The APN identifies the public GPRS network that the Communicator will connect to.
  • Page 25 [658] Interactive Access Point Name 1 Default ( ) This section is programmed as 32 character ASCII. Receiver 1 shall use this APN to connect to the Interactive network. Two sockets are opened, one for each receiver. If both APNs are left blank, the unit will eventually dis- play a Receiver not Available Trouble.
  • Page 26 [673] Lifestyle Zone 9 - 16 Toggle Options The default for each Lifestyle Zone Toggle is ON. Table 14: Lifestyle Zone 9 - 16 Toggle TOGGLE ZONE [674] Lifestyle Zone 17 - 24 Toggle Options The default for each Lifestyle Zone Toggle is ON. Table 15: Lifestyle Zone 17 - 24 Toggle TOGGLE ZONE...

  • Page 27: Receiver Diagnostic Testing

    [683] Notification Zone 9 - 16 Toggle Options The default for each Notification Zone Toggle is OFF. Table 22: Notification Zone 9 - 16 Toggle TOGGLE ZONE [684] Notification Zone 17 - 24 Toggle Options The default for each Notification Zone Toggle is OFF. Table 23: Notification Zone 17 - 24 Toggle TOGGLE ZONE...

  • Page 28: System Reset Defaults

    [991] Firmware Version This Section will display the current firmware version of the device. Update worksheets with new version after a flash update is completed. [992] Ethernet IP Address This Section will display the IP address of the Ethernet connection. This value is programmed in Section [001] or assigned by DHCP.

  • Page 29: Communicator Programming Worksheets

    |____| [3] Supervision Type Default (OFF). [026] Ethernet 1 Transmission |____| [4] Primary Communications Path. Default (FF) Program 00 disable or FF enable. Default [OFF] TL260GS-SM; [ON]GS2060-SM. |____|____| |____| [5] Redundant Communications Default (OFF). [027] Ethernet 2 Transmission |____| [6] Remote Firmware Upgrade Default (ON).

  • Page 30: Ethernet Receiver 2 Options

    [105] Ethernet Receiver 1 Local Port [206] GPRS Receiver 1 Domain Name Default ( )  Default (0BF4/3060) Valid range: 0000 - FFFF. Programming not permitted on UL/ULC listed system. 32 Character ASCII characters. |____|____|____|____| ____________________________________ [106] Ethernet Receiver 1 Domain Name Default () 32 ASCII characters.
  • Page 31 [652] Interactive Access Code [675] Lifestyle Zone 25 - 32 Toggle Options Default (1234) |____|____|____|____|____|____|____|____| |____|____|____|____| 25 26 27 28 29 30 31 32 [653] Interactive IP Address [676] Lifestyle Zone 33 - 40 Toggle Options Default (000.000.000.000) |____|____|____|____|____|____|____|____| [654] Interactive Remote Port 33 34 35 36 37 38 39 40 Default (0BFC/3068) [677] Lifestyle Zone 41 - 48 Toggle Options...

  • Page 32: Receiver Diagnostic Testing

    Receiver Diagnostic Testing [994] GPRS IP Address [901] Diagnostic Test Transmission |____|____|____||____|____|____||____|____|____|____|____|____| [995] SIM Number |___| [1] Ethernet 1 Default (OFF). ____________________________________ |___| [2] Ethernet 2 Default (OFF). [996] GSM Telephone Number |___| [3] GPRS 1 Default (OFF). This number is required for DLS, and Firmware |___| [4] GPRS 2 Default (OFF).

  • Page 33: End User Licence Agreement

    PARTICULAR PURPOSE) AND OF ALL OTHER OBLIGA- any changes or modifications to the Software, without the writ- TIONS OR LIABILITIES ON THE PART OF DSC. ten permission of an officer of DSC. You may not remove any MAKES OTHER WARRANTIES.

  • Page 34: Limited Warranty

    The laws of some jurisdictions limit or do not allow the delivery. In such cases, DSC can replace or credit at disclaimer of consequential damages. If the laws of its option.

  • Page 36: Fcc Compliance Statement

    Not all products include all features. Availability varies by region; contact your sales representative. 2 9 0 0 7 8 5 8 R 0 0 1 ©2011Tyco International Ltd. and its Respective Companies. All Rights Reserved Toronto, Canada  www.dsc.com Tech Support 1-866-910-3865 Printed in Canada...
