Unplug this connector
Stock connector
i113-411 www.powercommander.com
PCIIIr connectors
PCIII harness
Ground wire from PCIII
02-04 Honda CBR 1100 XX
1 Remove the seat.
2 Lift the front of the fuel tank up.
3 Unplug the grey connector from the
wiring harness (Fig. A). This connec-
tor is located on the left hand side of
the bike and comes from the throttle
bodies.
4 Plug the PCIII connectors in-line of
the stock connector (Fig. B).
5 Attach the ground wire from the PCIII
to the NEGATIVE side of the battery
(Fig. C).
(2001-2004 European Model)
- PCIII USB - 2
