EVAL-AD5344DBZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 5. EVAL-MBnanoDAC-SDZ
Reference Designator
C1, C6, C7, C9
C2, C5, C8, C10, C15 to C17
C3, C4
C11
EXT_REF_1 to EXT_REF_4
J1
J2
J3, J7, J8
J4
J5
J6
J9
J10
L1
LK5
LK6, LK7
REF1 to REF4
R1
R2, R3
R5 to R15
U2
U3
U4
U5
U6
U7
U10
U11, U12
1 FEC refers to Farnell Electronic Component Distributors.
GRM refers to Murata Manufacturing Company.
2
Motherboard
Description
6.3 V tantalum capacitors (Case A), 10 µF, ±20%
50V, X7R ceramic capacitors, 0.1 µF, ±10%
10 V, X5R ceramic capacitors, 1 uF, ±10%
6.3 V tantalum capacitor (Case A), 4.7 µF, ±20%
Straight PCB mount SMB jacks, 50 Ω
Header, 2.54 mm, 2 × 8-way
Header, 2.54 mm, 2 × 5-way
Headers, 2.54 mm, 1 × 6-way
Header, 2.54 mm, 1 × 8-way
3-pin terminal block
2-pin terminal block
Header, 2.54 mm, 2 x 4-way
120-way connector
Inductor, SMD, 600 Ω
6-pin (3 × 2-way) 0.1" header and shorting block
4-pin (2 × 2-way) 0.1" header and shorting blocks
10-pin (5 × 2-way) 0.1" header and shorting blocks
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistors, 100 kΩ, 1%, 0603
SMD resistors, 100 Ω, 1%, 0603
3.3 V linear regulator
32 kΩ I 2 C Serial EEPROM
5 V Reference MSOP
Ultralow noise XFET® voltage reference
4.096 V reference
Dual op amp
Quad op amp
Op amp
Rev. A | Page 11 of 12
Supplier 1 /Part Number
FEC 1190107
FEC 1759122
GRM188R61A105KA61D 2
FEC 1432350
FEC 1206013
FEC 2308428
FEC 9689583
FEC 9689508
FEC 1766172
FEC 1667472
FEC 151789
FEC 1667509
FEC 1324660
FEC 9526862
FEC 148-535 and FEC 150-411 (36-pin strip)
FEC 148-535 and FEC 150-411 (36-pin strip)
FEC 1022227 and FEC 150-411
FEC 1627674
FEC 9330402
FEC 9330364
ADP121-AUJZ33R7
FEC 1331330
ADR445ARMZ
ADR431BRZ
REF198ESZ
AD8616ARZ
AD8608ARMZ-R7
AD8655ARMZ
UG-985
