Table 6.

EVAL-AD5344DBZ

Reference Designator

Description

Red test point, do not insert

Not inserted

50 V X7R ceramic capacitor

6.3 V tantalum capacitor (Case A)

Red test point, do not insert

16-pin (2 × 8-way) header, inserted from solder side

10-pin (2 × 5-way) straight header, 2.54 mm pitch, inserted from solder side

6-pin (1 × 6-way) straight header, 2.54 mm pitch, inserted from solder side

Header, 2.54 mm, PCB, 1 × 8-way, inserted from solder side

Jumper block using a 3-pin SIP header

Not inserted

Quad 12-bit DAC

FEC refers to Farnell Electronic Component Distributors.

C refers to a communication protocol originally developed by Philips Semiconductors (now NXP Semiconductors).
