Introduction

This document describes the hardware interface of the Intel® Edison kit for Arduino*.
The kit contains external input/output pin connections which may be configured to be used in a variety of
interfacing modes, such as GPIO, PWM, SPI, I
document describes the pin functions available, detailed GPIO pin mapping for pin control and I/O, and use of
Linux command line tools to configure the external I/O pin functions correctly for the desired mode of operation.
1.1

Software requirements

•
Intel® Edison kernel and BSP.
•
Access to the Linux command line on an Intel® Edison compute module.
1.2

Terminology

Term Definition
Pulse width modulation
PWM
General purpose input/output
GPIO
Analog to digital converter
ADC
Serial peripheral interface
SPI
Inter-integrated circuit
I 2 C
1.3

References

Table 1 Product-specific documents
Reference Name
Intel® Edison Board Support Package User Guide
331188
Intel® Edison Compute Module Hardware Guide
331189
Intel® Edison Breakout Board Hardware Guide
331190
Intel® Edison Kit for Arduino* Hardware Guide
331191
Intel® Galileo and Intel® Edison Release Notes
329686
Intel® Edison Getting Started Guide
[GSG]
Intel® Edison Wi-Fi Guide
331438
Intel® Edison Kit for Arduino*
Hardware Guide
6
2
C, ADC, for compatibility with Arduino* Uno* shield hardware. This
Number/location
(This document)
W: https://communities.intel.com/docs/DOC-23147
M: https://communities.intel.com/docs/DOC-23148
L: https://communities.intel.com/docs/DOC-23149
§
Shield pin configuration
December 2014
Document Number: 331191-004
