Trinabess Power Box Installation Manual page 33

6.3.2 Event List
2.Event List
Event list of POWER BOX includes current event list and history event list.
1） Current Event List
Select "1. Current Event List", press "OK" to check the current events.
2） History Event List
Select "2. History Event List", press "OK" to check the history events. Press "up"
or "down" to check all history events if there're more than 1 page of events.
6.3.3 System information interface
3.System
Information
6.3.4 Software upgrading
Select "4. Software Update" in the main menu, press "OK", "input password" is
shown, press "OK" again. Input the password ("0715"), press "Up" or "Down" to
change the 1 digit, press "OK" to switch to next digit, when "0715" is shown on
st
the screen, press "OK". The POWER BOX will start to upgrade the software
automatically.
It's easy to upgrade the software of the POWER BOX. New software includes new
features & improvements for reliability.
Upgrading Procedure:
Step 1 Turn off the DC isolator (PowerCube 2.0) and AC circuit breaker (grid), then
remove the communication waterproof cover (as shown in the following picture).
If the communication cables (RS485, NTC, CT) have been connected, please
loosen their cable glands before removing the waterproof cover.
1.Current Event List
2.History Event List
1.Product SN
2.Software Version
3.Hardware Version
4.RS485 Address
5.Country
6.Power Factor
7.EPS Mode
8.Batt Parameter
9.Setting Pf time
10.Setting QV time
11. Defa. Pf time
12. Defa. QV time
