Trinabess Power Box Installation Manual page 30

3) Setting Pf time
After entering Auto Test interface, press "up" or "down" to select "3.Setting Pf
time", then press "OK" to enter Setting Pf time interface.
After entering Setting Pf time interface, it will display as below:
Set: *. *** s
*. *** is the time value need to be set. Press "Up" or "Down" to change the 1
digit, press "OK" to switch to next digit. After inputting numbers for all digits,
press "OK".
4) Setting QV time
After entering Auto Test interface, press "up" or "down" to select "4.Setting QV
time", then press "OK" to enter Setting QV time interface.
After entering Setting QV time interface, it will display as below:
Set：** s
** is the time value need to be set. Press "Up" or "Down" to change the 1
press "OK" to switch to next digit. After inputting numbers for all digits, press
"OK".
5) Control 81.S1
After entering Auto Test interface, press "up" or "down" to select "5.Control
81.S1". After entering control 81.S1 interface, press "up" or "down" to select "1.
Enable 81.S1" or "2. Disable 81.S1", press "OK".
12. Work Mode Set
Select "12. Work Mode Set", press "OK" to enter work mode setting interface.
12.Work Mode Set
1) Set Auto Mode
Select "1. Set Auto Mode", then press "OK".
In auto mode, the device will automatically determine the charging time &
discharging time, & ensure that the SOC (State of Charge) of PowerCube 2.0
won't be too low.
↓
Test 81<S2 OK!
↓
81<S2:50.0Hz82ms
↓
Auto Test OK!
1.Set Auto Mode
2.Set Time-of-use Mode
3.Set Timing Mode
Wait
Press "Down" to see
results
st
st
digit,
