Trinabess Power Box Installation Manual page 23

1. Batt Parameter
1.Batt Parameter
Press the "back" button to enter main menu, select "1. Enter Setting", press
"OK". Select "1. Batt Parameter" and press "OK", "input password" is shown,
press "OK" again. Input the password (normal "0001", advanced "0715"),
press "Up" or "Down" to change the 1
when "0001 / 0715" is shown on the screen, press "OK" to enter "Batt
Parameter" interface. If "Error! Try again" is shown on the screen, press "Back"
and input the password again.
1) Battery Type
Select "1. Battery Type" and press "OK". Press "up" or "down" to select the
battery and then press "OK".
2) Battery Capacity
Select "2. Battery Capacity" and press "OK". Press "up" or "down" to change
the 1st digit, press "OK" to switch to next digit. Input the value of battery
capacity. Press "OK".
3) Discharge Depth
Select "3. Discharge Depth" and press "OK". Press "up" or "down" to change
the 1 digit, press "OK" to switch to next digit. Input the value of Depth of
st
Discharge per battery specification. Press "OK".
For example: if Depth of Discharge = 80%, the POWER BOX won't discharge
the battery when its SOC (State of Charge) is less than 20%.
4) Max. Charge (A)
Select "4. Max. Charge (A)" and press "OK". Press "up" or "down" to change
the 1 digit, press "OK" to switch to next digit. Input the value of the Max.
st
Charge (A) per battery specification. Press "OK".
5) Over (V) Protection
Select "5. Over (V) Protection" and press "OK. Press "up" or "down" to change
the 1 digit, press "OK" to switch to next digit. Input the value of Over (V)
st
Protection per battery specification. Press "OK".
1.Battery Type
2.Battery Capacity
3.Discharge Depth
4.Max. Charge (A)
5.Over (V) Protection
6.Min. Discharge (V)
7.Max. Discharge (A)
8.Low (V) Protection
9.Max. Charge (V)
10.Discharge Time
11.Empty Charged Voltage
12.Full Charged Voltage
digit, press "OK" to switch to next digit,
st
