2. Clear Energy Data
Select "2. Clear Energy" and press "OK", "input password" is shown, press
"OK" again. Input the password "0001/0715", press "Up" or "Down" to change
the 1 digit, press "OK" to switch to next digit, when "0001" is shown on the
st
screen, press "OK". If "Error! Try again" is shown on the screen, press "Back"
and input the password again.
3. Clear Events
Select "3. Clear Events", press "OK" button twice to clear all the events.
4. Set Country
Select "4. Set Country", press "OK", "Input Country Code" is shown, press "OK",
if "Set Disable" is shown, you need to go to "6. Function to Set Country" to
enable country setting, then return to "4. Set Country" to input the country
code (refer to Page 17 of this manual). Press "OK".
5. Set Communication Add
Select "5. Set Communication Add", press "OK" button twice to enter
Communication Address setting interface. Press "Up" or "Down" to change the
1 digit, press "OK" to switch to next digit, after inputting the communication
st
address, press "OK".
6. Function to Set Country
Select "6. Function to Set Country", press "OK", "input password" is shown,
press "OK" again. Input the password "0001", press "Up" or "Down" to change
the 1 digit, press "OK" to switch to next digit, when "0001" is shown on the
st
screen, press "OK". If "Error! Try again" is shown on the screen, press "Back"
and input the password again.
CODE
00 Germany4105
01
02
03 SpainRD1699
04
05
06 Greece Continent
07
08
09
10
Country
CEI021_INT
Australia
Turkey
Denmark
Netherland
Belgium
UK_G59
China
CODE
14
15
16
17
18
19
20
21
22
23
24
Country
Germany_0126
Italy_CEI0_16
UK_G83
Greece island
EU_EN50438
EU_EN61727
Korea
Sweden
Europe general
CEI021_EXT
Cyprus
