INSTALLATION AND SERVICING INSTRUCTIONS
WALL HUNG GAS FIRED CONDENSING BOILER
WORCESTER COMMERCIAL BOILER SERIES
GB162-65/80/100
FOR CENTRAL HEATING SYSTEMS AND INDIRECT FED DOMESTIC HOT WATER
