48-635 E3 Modulevel ® Displacer Level Transmitter
2.6

Configuring the Transmitter

The E3 MODULEVEL transmitter comes calibrated from
the factory.
Information on configuring the transmitter using a HART
communicator is given in Configuration Using HART,
Section 2.7.

2.6.1 Operating Parameters

Some key information is needed to configure the E3 trans-
mitter. Complete the configuration information table. See
Configuration Information, Section 1.1.2.

2.6.2 Transmitter Display and Keypad

The E3 transmitter has a liquid-crystal display (LCD) capa-
ble of showing two lines of 8 characters each. Transmitter
measurements and configuration menu screens are shown
on the LCD.
The transmitter default display is the measurement screen.
It cycles every 5 seconds to display STATUS, LEVEL,
%OUTPUT, and LOOP information. The transmitter
defaults to this display after 5 minutes of keypad inactivity.
The keypad has three buttons used to scroll through the dis-
plays and to calibrate the transmitter – the
and the key.
Function in
Arrows Display Mode
Up and Down Moves forward and backward
in the configuration program
from one display to another.
Enter Enters the configuration mode
(noted by an exclamation point to the display mode.
as the last character in the top
display line).
and keys
Function in
Configuration Mode
Increases or decreases the
value displayed or moves to
another choice.
NOTE: Hold arrow key for
rapid scrolling.
Accepts a value and returns
15
