2.6.5.1 Measurement Type: Level Only (cont.)
Display
Factory Cal
Menu
38a
User Cal Menu
38b
AdjSnrLo
39
AdjSnrHi
4
Conv Fct
xxxx
41
Scl Ofst
xxx
42
LVDT%
xx.xx %
43
Chan 0
44
Chan 1
45
NSP Value
46
ElecTemp
xxx F
47
Max Temp
xxx F
48
Min Temp
xxx F
49
2.6.5.1 Measurement Type: Level Only: Factory (display only) or User Calibration sub-menu
Display
LVDT%
xx.xx %
1
Calib SG
x.xxx sg
2
DrySensr
xx.xx %
3
SnrCalLo
xx.xx %
4
LvlCalLo
xx.xx lu
5
Set 4mA
xx.xx lu
6
SnrCalHi
xx.xx %
7
LvlCalHi
xx.xx lu
8
Set 20mA
xx.xx lu
9
Escape
1
48-635 E3 Modulevel ® Displacer Level Transmitter
Action
Press to display the
Factory Calibration sub-menu
Press to display the User
Calibration sub-menu
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Action
Diagnostic display
Factory set
Enter or capture sensor
output for Dry Sensor
Enter or capture sensor
output for Low Cal Point
Enter Level value
corresponding to SnrCalLo
Enter the level value for
4 mA set point
Enter or capture sensor
output for High Cal Point
Enter Level value
corresponding to SnrCalHI
Enter the level value for
20 mA set point
Press to exit Calibration
sub-menu; Returns to
Factory Menu
Comment
CalSelct = Factory
Submenu on page 19
CalSelct = User
Submenu below
Present temperature in electronics compartment
Maximum electronics temperature recorded
Minimum electronics temperature recorded
Comment
Factory calibration menu only
Press and simultaneously to capture current
sensor output
Press and simultaneously to capture current
sensor output
Specify level at 4 mA (User Cal menu only)
Press and simultaneously to capture current
sensor output
Specify level at 20 mA (User Cal menu only)
