Atex; Explosion Protection) - Magnetrol E3A Modulevel Installation And Operating Manual

Agency Model

ATEX

EXX-XXXX
EXX-XXXX
EXX-XXXX
IEC EXX-XXXX
EXX-XXXX
¿
On remote electronics housing only, seal is required within 18 inches.
¡
Entity parameters for intrinsically safe installation:
FM/CSA
V = 28.6 V P
max max
I = 140 mA C = 5.5 nF
max i
ATEX
V = 28.4 V P
max max
I = 94 mA C = 2.2 nF
max i
48-635 E3 Modulevel ® Displacer Level Transmitter
Transmitter Codes
Digits 8, 9 and 10
x1E, x1F, x1G, x1H
x2E, x2F, x2G, x2H
x3E, x3F, x3G, x3H
x4E, x4F, x4G, x4H
x5E, x5F, x5G, x5H
x6E, x6F, x6G, x6H
x8E, x8F, x8G, x8H
x1A, x1B, x1C, x1D
x2A, x2B, x2C, x2D
x3A, x3B, x3C, x3D
x4A, x4B, x4C, x4D
x5A, x5B, x5C, x5D
x6A, x6B, x6C, x6D
x8A, x8B, x8C, x8D
x1A, x1B, x1C, x1D
x2A, x2B, x2C, x2D
x3A, x3B, x3C, x3D
x4A, x4B, x4C, x4D
x5A, x5B, x5C, x5D
x6A, x6B, x6C, x6D
x8A, x8B, x8C, x8D
x1E, x1F, x1G, x1H
x2E, x2F, x2G, x2H
x3E, x3F, x3G, x3H
x1A, x1B, x1C, x1D
x2A, x2B, x2C, x2D
x3A, x3B, x3C, x3D
= 1 W L = 9.4 µH
i
= 0.67 W L = 3 µH
i
Approval/Standards
Flameproof
ATEX Ex II 1/2 G Ex d IIC T6
EN 60079-0, EN 60079-1,
EN 60079-26
94/9/EC
Intrinsically Safe ¡
ATEX Ex II 1 G Ex ia IIC T4
EN 60079-0, EN 60079-11,
EN 60079-26, EN 60079-27
94/9/EC
Non-Sparking
ATEX Ex II 3 G Ex ic II T6
EN 60079-0
EN 60079-11
94/9/EC
Flameproof
IECEx Ex d IIC T6 Ga/Gb
IEC 60079-0
IEC 60079-1
IEC 60079-26
¡
Intrinsically Safe
IECEx Ex ia IIC T4 Ga
IEC 60079-0
IEC 60079-11
IEC 60079-26
IEC 60079-27
These units have been tested to
EN 61326 and are in compliance with
the EMC Directive 2004/108/EC.
33
