Assembly
4.4.
Accessories for assembly
4.4.1.
Stem protection tube for rising valve stem
16
— Option —
Figure 10: Assembly of the stem protection tube
[1]
Cap for stem protection tube
[2]
Stem protection tube
[3]
Sealing ring
1.
Seal thread with hemp, Teflon tape, or thread sealing material.
2.
Screw stem protection tube [2] into thread and tighten it firmly.
3.
Push down the sealing ring [3] onto the housing.
4.
Check whether cap for stem protection tube [1] is available and in perfect con-
dition.
SAEx 07.2
SAEx 16.2 / SAREx 07.2
SAREx 16.2
