Identification
Order number
Serial number
Data Matrix code
2.2.

Short description

Multi-turn actuator
10
The product can be identified using this number and the technical data as well as
order-related data pertaining to the device can be compiled.
Please always state this number for any product inquiries.
On the Internet at http://www.auma.com, we offer a service allowing authorised
users to download order-related documents such as wiring diagrams and technical
data (both in German and English), inspection certificates and the operation
instructions when entering the order number.
Table 2: Description of serial number (with example)
05 14 MD12345
st nd
1 +2 position: Assembly in week
05 Week 05
rd th
3 +4 position: Year of production
14 Year of production: 2014
All other positions
MD12345 Internal number for unambiguous product identification
When registered as authorised user, you may use the AUMA Support App to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order number of serial number.
Figure 5: Link to the App store:
Definition in compliance with EN ISO 5210:
A multi-turn actuator is an actuator which transmits to the valve a torque for at least
one full revolution. It is capable of withstanding thrust.
AUMA multi-turn actuators are driven by an electric motor and are capable of
withstanding thrust in combination with output drive type A. For manual operation,
a handwheel is provided. Switching off in end positions may be either by limit or
torque seating. Controls are required to operate or process the actuator signals.
Actuators without controls can be equipped with AUMA actuator controls at a later
date. For more information, please state our order number (refer to actuator name
plate).
SAEx 07.2 SAEx 16.2 / SAREx 07.2 SAREx 16.2
