SMCWEB-N2 Wireless N Universal Repeater User Manual
Parameter configuration for PPPoE
c
Step 5 Cli k Next. Set the SSID and password and note them down. Click
Finish to complete the settings.

6.3 Repeater Mode Configuration

Step 1 Set the three-way switch on the side panel to Repeater after
SMCWEB-N2 is powered on. Log in to the configuration page after the
system is started.
Step 2 Click Setup Wizard in the navigation bar on the left pane of the page.
Select Wireless Universal Repeater Mode and click Next.
Enter the account name and
password for Internet
connection
Enter the DNS address
provided by your ISP. If your
ISP does not provide it, select
Get Automatically From ISP.
You can use the default SSID.
However, we suggest modifying SSID.
- 31 -
Set the wireless encryption
mode and password.
