SMCWEB-N2 Wireless N Universal Repeater User Manual
Note:
After the software upgrade, SMCWEB-N2 returns to the factory default
settings. In case of losing the previous configuration information, please
save settings before updating the software.
Do not power off the router during the upgrade.

10 Web Configuration for the WDS Mode

10.1 Running Status

Click Running Status and the extended navigation menu is shown as follows:
Click the submenu to enter a specific configuration page.

10.1.1 Router Status

Choose Running Status > Router Status and the Router Status page is
displayed.
- 121 -
