S S p p e e c c i i f f i i c c a a t t i i o o n n s s
General specifications
Video@1Vp-p, 75 ohm,
Input signal levels Y@1 Vp-p, 75 ohm
Color@ 0.7 Vp-p, 75 ohm
Output Format Digital RGB
Output Connector HDMI Type A female
Output Signal Bit stream
Weight 400g
Dimensions 125(W) x 123(D) x 30(H) mm
Output Signal specifications
HDMI connector pin assignment
