UG-478

EVALUATION BOARD HARDWARE

DEVICE DESCRIPTION

The AD7176-2 is a low noise, fast settling, multiplexed, 2-/4-
channel (fully differential/pseudo differential) Σ-Δ ADC. The
AD7176-2 has a maximum channel-to-channel scan rate of
50 kSPS (20 µs) for fully settled data. The output data rates
range from 5 Hz to 250 kHz.
Complete specifications for the
product data sheet and should be consulted in conjunction with
this user guide when using the evaluation board. Full details
Table 1. Default Link and Solder Link Options
Link No. Default Option
LK1 A
LK2 A
LK5 to LK9 Inserted
SL1 A
SL2 A
SL3, SL7 A, A
SL4 A
SL5 B
SL6 Not Inserted
SL8 B
AD7176-2 are provided in the
Description
Connects the AVDD1 voltage to the power supply sequencer, ADM1185.
When AVDD1 equals 5 V, LK1 must be in Position A.
When AVDD1 equals 2.5 V, LK1 must be in Position B.
Selects the connector for the external 7 V to 9 V power supply.
In Position A, this link selects the external 7 V to 9 V power supply to come from Connector J4.
In Position B, this link selects the external 7 V to 9 V power supply to come from Connector J5.
Inserting LK5 to LK9 sets up the on-board noise test. In this mode, all inputs are shorted to the REFOUT pin.
Sets the voltage applied to the AVDD2 pin.
In Position A, this link sets the voltage applied to the AVDD2 pin to be the same voltage applied to the
AVDD1 pin.
In Position B, this link sets the voltage applied to the AVDD2 pin to be a 3.3 V supply from the
regulator or from an external voltage.
AVDD2 cannot be set to 3.3 V when AVDD1 equals 2.5 V and AVSS equals −2.5 V.
Sets the voltage applied to the AVDD1 pin.
In Position A, this link sets the voltage applied to the AVDD1 pin to be a 5 V supply from the
regulator or a 2.5 V supply from the
In Position B, this link sets the voltage applied to the AVDD1 pin to be supplied from an external voltage
source via Connector J9.
When AVDD1 equals 2.5 V, AVSS can be set to −2.5 V using an external supply connected to Connector J9. The
AVSS to AGND solder links must be removed when a split power supply is used.
With SL3 and SL7 in Position A, AVDD1 is supplied with 5 V from
With SL3 and SL7 in Position B, AVDD1 is supplied with 2.5 V from the
With this link in Position A, the AIN4 analog input on the
With this link in Position B, the AIN4 analog input is connected to the REFOUT pin of the AD7176-2.
With this link in Position C, the AIN4 analog input is connected to ground for use with four pseudo
differential inputs, if required.
With this link in Position A, the IOVDD supply is provided from an external source via Connector J9.
With this link in Position B, the 3.3 V supply is generated by the
The evaluation system operates with 3.3 V logic.
Allows an external crystal or clock to be used as the clock source for the AD7176-2.
With SL6 not inserted, a crystal is connected to the AD7176-2.
With SL6 in Position B, an external clock source can be supplied to the ADC.
With this link in Position A, the AIN1 analog input on the
With this link in Position B, the analog input applied via Connector J8 is buffered using the
being applied to the AIN1 pin.
With this link in Position C, the analog input path includes the ADA4940-1 differential amplifier; therefore,
in conjunction with AIN0, a single-ended to differential driver is implemented.
With this link in Position D, AIN1 is connected to Header J10.
about the EVAL-SDP-CB1Z are available on the Analog
Devices, Inc., website.

HARDWARE LINK OPTIONS

The default link options are listed in Table 1. By default, the
board is configured to operate from the external bench top
power supply via Connector J4. The supply required for the
AD7176-2 comes from the on-board
generate their input voltage from J4.
ADP1720 (U4) regulator.
AD7176-2
AD7176-2
Rev. 0 | Page 4 of 40
Evaluation Board User Guide
ADP1720
ADP1720-3.3
ADP1720-5 (U7) regulator.
ADP1720 (U4) regulator.
device is connected to Connector J8.
ADP1720-3.3 (U10) regulator.
device is connected to Connector J8.
LDOs, which
(U10)
ADP1720-5 (U7)
AD8656 before
