Evaluation Board User Guide

SOCKETS/CONNECTORS

Table 4. Connector Details
Connector Function
J1 Connector to EVAL-SDP-CB1Z
J2 External MCLK (SMA/SMB)
A0 to A4 Analog inputs to ADC
J4 External bench top voltage
supply for EVAL-AD7176-2SDZ
J5 External wall wart voltage supply
(7 V to 9 V) for EVAL-AD7176-2SDZ
J8 Analog input screw terminal
block; wired connection to
external source or sensor
J9 External bench top voltage supply
option for AVDD1/AVDD2 and
IOVDD inputs on
J10 External amplifier connector
J13 Connects to AIN0/AIN1 analog
inputs of ADC
Connector Type
120-way connector, 0.6 mm pitch
Straight PCB mount SMB/SMA jack
Straight PCB mount SMB/SMA jack
3-pin socket terminal block,
3.81 mm pitch
DC power connectors, 2 mm SMT
power Jack
8-pin terminal header, 3.81 mm pitch,
vertical
Screw terminal block, 3.81 mm pitch
AD7176-2 device
7-pin, SSW, 2.54 mm vertical socket
7-pin, SIP, 2.54 mm through hole
header
Manufacturer/Part No.
Hirose FX8-120S-SV(21)
Tyco 1-1337482-0
Tyco 1-1337482-0
Phoenix Contact MC 1,5/ 3-G-3,81
Kycon KLDX-SMT2-0202-A
Phoenix Contact MC 1.5/ 8-G-3.81
Phoenix Contact 1727036
Samtec SSW-107-01-T-S
Samtec TLW-107-05-G-S
Rev. 0 | Page 7 of 40
UG-478
Order No.
Farnell 1324660
Not inserted
Not inserted
Farnell 3704737
Mouser 806-KLDX-
SMT20202A
Farnell 3704774
Farnell 370-4592
Farnell 1803478
Farnell 1668499
