Analog Devices EVAL-AD7176-2SZD User Manual page 36

UG-478
Name Value 1 Tolerance
R48 100k 1%
R49 0R 0.01
R50 0R 0.01
R51 0R 0.01
R52 0R 0.01
R53 60k4 0.01
R54 4k53 0.01
R55 61R9 0.01
R60 2k4 0.01
R61 0R 0.01
R62 0R 0.01
R63 0R 0.01
R64 DNI 0.01
R65 0R 0.01
R66 1k 0.01
R67 DNI 0.01
R68 1k 0.1%
R69 DNI 0.01
R70 0R 0.01
R71 10k 0.01
R72 0R 0.01
R73 0R 0.01
R74 DNI 0.01
R75 1k 0.01
R76 1k 0.01
R77 1k 0.01
R78 0R 0.01
R79 DNI 0.01
R80 DNI 0.01
R81 0R 0.01
R82 0R 0.01
PCB Decal Description
R0603 SMD resistor
1206 Resistor, 1206
1206 Resistor, 1206
1206 Resistor, 1206
1206 Resistor, 1206
R0402 Resistor, 0402, 60k4
R0402 Resistor, thick film, 4.53 kΩ,
63 mW, 1%
R0402 Resistor, 0402, 1%, 61R9
R0603 Resistor, thick film, 2.4 kΩ, 0603,
100 mW, 1%
R0402 Resistor, 0402
R0402 Resistor, 0402
R0603 Resistor, 0603
R0603 Resistor, not inserted, 0603
R0603 Resistor, 0603
R0603 Resistor, 0603, thick film, 1%
R0603 Resistor, not inserted, 0603
R0603 Resistor, 0603
R0603 Resistor, not inserted, 0603
R0402 Resistor, 0402
R0402 Resistor, 1%, 0402
R0603 Resistor, 0603
R0603 Resistor, 0603
R0603 Resistor, not inserted, 0603
R0603 Resistor, 0603, thick film, 1%
R0603 Resistor, 0603, thick film, 1%
R0603 Resistor, 0603, thick film, 1%
R0603 Resistor, 0603
R0603 Resistor, not inserted, 0603
R0603 Resistor, not inserted, 0603
R0603 Resistor, 0603
R0603 Resistor, 0603
Rev. 0 | Page 36 of 40
Evaluation Board User Guide
Manufacturer Part No.
Multicomp MC 0.063W
0603 1% 100K
Multicomp MC 0.125W
1206 0R
Multicomp MC 0.125W
1206 0R
Multicomp MC 0.125W
1206 0R
Multicomp MC 0.125W
1206 0R
Multicomp MC 0.0625W
0402 1% 60K4
Vishay Dale CRCW04024K5
3FKED
Multicomp MC 0.0625W
0402 1% 61R9
Yageo RC0603FR-
072K4L
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW06031K0
0FKEA
Vishay Draloric CRCW0603000
0Z0EA
Panasonic ERA3AEB102V
N/A N/A
Vishay CRCW0402000
0Z0ED
Phycomp CRCW040210K
0FKEAHP
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW06031K0
0FKEA
Vishay Draloric CRCW06031K0
0FKEA
Vishay Draloric CRCW06031K0
0FKEA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Vishay Draloric CRCW0603000
0Z0EA
Stock Code
FEC 9330402
FEC 9336974
FEC 9336974
FEC 9336974
FEC 9336974
FEC 1803729
FEC 1151244
FEC 1802915
FEC 1799329
FEC 146-9661
FEC 146-9661
FEC 146-9739
Do not insert
FEC 146-9739
FEC 1469740
Do not insert
FEC 157-7605
Do not insert
FEC 146-9661
FEC 173-8864
FEC 146-9739
FEC 146-9739
Do not insert
FEC 1469740
FEC 1469740
FEC 1469740
FEC 146-9739
Do not insert
Do not insert
FEC 146-9739
FEC 146-9739
