Evaluation Board User Guide
Name Value 1 Tolerance
R17 10k2 0.01
R18 10k2 0.01
R19 0R 0.01
R20 0R 0.01
R21 0R 0.01
R22 0R 0.01
R23 86k6 0.01
R24 10k2 0.01
R25 30k1 0.01
R26 DNI 0.01
R27 0R 0.01
R28 DNI 0.01
R29 DNI 0.01
R30 0R 0.01
R31 DNI 0.01
R32 0R 0.01
R33 DNI 0.01
R34 0R 0.01
R35 0R 0.01
R36 0R 0.01
R37 0R 0.01
R38 0R 0.01
R39 0R 0.01
R40 0R 0.01
R41 0R 0.01
R42 10k 0.05
R43 10k 0.05
R44 10k 0.05
R45 10k 0.05
R46 0R 0.01
R47 0R 0.01
PCB Decal Description
R0402 SMD resistor
R0402 SMD resistor
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402, 1%, 86k6
R0402 SMD resistor
R0402 Resistor, 0402, 1%, 30k1
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, not inserted, 0402
R0402 Resistor, not inserted, 0402
R0402 Resistor, 0402
R0402 Resistor, not inserted, 0402
R0402 Resistor, 0402
R0402 Resistor, not inserted, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, 0402
R0402 Resistor, thick film, 10 kΩ,
62.5 mW, 5%
R0402 Resistor, thick film, 10 kΩ,
62.5 mW, 5%
R0402 Resistor, thick film, 10 kΩ,
62.5 mW, 5%
R0402 resistor, thick film, 10 kΩ,
62.5 mW, 5%
R0402 Resistor, 0402
R0402 Resistor, 0402
Rev. 0 | Page 35 of 40
Manufacturer Part No.
Multicomp MC 0.0625W
0402 1% 10K2
Multicomp MC 0.0625W
0402 1% 10K2
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Multicomp MC 0.0625W
0402 1% 86K6
Multicomp MC 0.0625W
0402 1% 10K2
Multicomp MC 0.0625W
0402 1% 30k1
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
N/A N/A
N/A N/A
Vishay CRCW0402000
0Z0ED
N/A N/A
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
Yageo RC0402JR-
1310KL
Yageo RC0402JR-
1310KL
Yageo RC0402JR-
1310KL
Yageo RC0402JR-
1310KL
Vishay CRCW0402000
0Z0ED
Vishay CRCW0402000
0Z0ED
UG-478
Stock Code
FEC 1803137
FEC 1803137
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 1803744
FEC 1803137
FEC 1803699
Do not insert
FEC 146-9661
Do not insert
Do not insert
FEC 146-9661
Do not insert
FEC 146-9661
Do not insert
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 146-9661
FEC 179-9316
FEC 179-9316
FEC 179-9316
FEC 179-9316
FEC 146-9661
FEC 146-9661
