RUNNING AMP POWER CABLE AND REAR SPEAKER WIRE
AMP PLATE INSTALLATION
2
Place the pre-installed amp plate with MRB3 Brain on the frame of the dash and line up the hole on the top
of the amp plate to the factory hole where the pocket bracket was previously installed (1). Loosely screw in
the factory 10mm screw in this hole location that was previously removed.
Next loosely screw in the M6 screw with washer from underneath the steering column into the amp plate (2).
Lastly hand tighten both screws.
THIS CONCLUDES THE DISASSEMBLY AND RUNNING OF THE POWER AND SPEAKER WIRE. NOW
REFER TO INSTRUCTION 1 - INSTALLATION OF THE GLOVEBOX SUBWOOFER ENCLOSURE.
TOP VIEW
E
E. Route the front speaker wire through the opening where the firewall and roll
cage bar meet on both the driver and passenger side. Leave these wires loose
until the front speaker pods are to be installed.
E
1
2
UNDERNEATH VIEW
1
E
7
