PANELS AND DASH DISASSEMBLY
A. Remove all seats by releasing the handle behind each seat,
push forward slightly while lifting up.
C. Remove hood by turning locking pins and lifting up.
E. Disconnect all harness connectors attached to the center dash panel.
A
B. Disconect the negative battery cable from the battery.
C
D. Remove center dash by unscrewing the 2 T-30 Torx screws and push center
dash forward to unclip.
E
F. Un-pin and pull to remove the passenger side safely handle.
D
B
D
F
4
