the Watch Window closes.
Save Selections
By clicking on Save Selections, the user can save the specific parameters that have been added to the Watch Window. Once the selections
have been saved, the Restore Selections button can be used to monitor all the same parameters the next time the user opens the Watch
Window. Therefore, if there is a list of helpful diagnostic parameters the user wishes to see when online, those specific parameters can be
saved and recalled in the Watch Window at any time. The settings can be saved in the default file named "fm3watch.wch" or the user can
create their own file. Setup the parameter that will be displayed in the Watch Window, enter the file name in the Selection File text box, then
click the Save Selections button.
Restore Selections
By clicking on the Restore Selections button, the Watch Window will be filled with the list of parameters that were last saved using the Save
Selections button.
Select Defaults
The Select Defaults button adds the most commonly used parameters to the Watch Window.
Select I/O
The Select I/O button will add the drive digital inputs and outputs to the Watch Window.
Not Moving?
The Not Moving? button will load the watch window with a list of predefined parameters (shown in the following table) that will give an
indication why the motor is not moving.
DriveEnableStatus
PowerStageEnabled
PowerSupplyReady
AbsolutePosnValid
FeedRateOverride
FeedRateDeactivate
SoftwareTravelLimitMinusActive
SoftwareTravelLimitPlusActive
Profile.0.MotionStop
Profile.0.FeedHold
Profile.1.MotionStop
Profile.1.FeedHold
202
Parameters Expected Value to get Motion
Fault.Faulted
DriveOK
Stop
MotionStop
SoftDriveDisable
InPosn
Feedhold
FoldbackActive
TorqueLimitActive
www.controltechniques.com
True
False
True The drive status must be ok to enable motion.
True
False
PowerSupplyReady will become inactive if the 24 volt
True logic power is taken away or if the bus voltage drops
False
False Motion is prevented by SoftDriveDisable.
Absolute indexes can not executed until the Absolute
True
If using "In Position" the last index is not considered
complete until this status is met. So motion will stop if
True you can not achieve in position. While running this is
expected to be false as it is only true at the end of a
False
Feed rate scales the speed of the Motion. 100%
100%
Activate to disable FeedRate. If feedrate is 100% it
False / True
When Foldback is active it indicates a current
overload and the Foldback circuit is limiting the
False
current. Foldback in it's self indicates motor selection
of wiring problems that effect motor motion.
False Motion stops when a travel limit is active.
False Motion stops when a travel limit is active.
Torque limits may effect motor motion as it reduces
False
Each profile has it's own Stop. To get motion out of
False
Each profile has it's own FeedHold. To get motion out
False
of this profile this parameter must be false.
Each profile has it's own Stop. To get motion out of
False
Each profile has it's own FeedHold. To get motion out
False
of this profile this parameter must be false.
Comments
Drive must be enabled.
Motion stops on a fault.
Must have power to move the motor.
Motion is stopped if stop is active.
below the "low bus fault" threshold.
Motion is stopped on motion stop.
position is defined.
move and prior to starting a new move.
Feed Hold stops motion.
scaling indicates one to one scaling.
does not matter.
motor generated torque.
this profile this parameter must be false.
this profile this parameter must be false.
