4.5

Adding and Deleting Programs

Programs can be added or removed from the user configuration in three ways. Programs may only be added or deleted while offline.
4.5.1

PowerTools Toolbar Button Method

Add Program Button
The Add Program button (shown below) will add a new program to the user configuration. Programs are added in sequential order. Clicking on
the button will add a program and bring you to the program-editing view allowing you to enter program instructions.
Delete Program Button
The Delete Program button (shown below) will delete a program from the user configuration. The highest numbered program will automatically
be deleted unless a different program is selected on the Programs heading screen. To delete a specific program, click on the Programs branch
in the Hierarchy Tree. From this view, select the specific program you wish to delete, and then click on the Delete Program button.
4.5.2

Power Tools Menu Bar Method

Adding a Program
From the PowerTools Pro menu bar, select Edit/New/Program. A program will be added in sequential order and you will be brought to the
program-editing view allowing you to enter program instructions.
Deleting a Program
Navigate to the Programs view on the Hierarchy Tree, and select the program you wish to delete. From the PowerTools Pro menu bar, select
Edit/Delete/Program. The selected Program will be deleted from the configuration.
4.5.3

Right Click Method

Adding a Program
Navigate to the Programs view in the Hierarchy Tree. Position your mouse pointer on the right side of the view and right-click. A selection
menu will appear allowing you to add a New Program or Delete a Program. Click on New Program and a program will be added in sequential
order and you will be brought to the program-editing view allowing you to enter program instructions.
Deleting a Program
Navigate to the Programs view in the Hierarchy Tree. Select the program you wish to delete and then right-click on your mouse. A selection
menu will appear allowing you to add a New Program or Delete a Program. Click on Delete Program and the selected program will be deleted
from the configuration.
4.5.4

Run Anytime Programs

The programming environment has been designed to automatically stop all programs when a fault occurs (regardless of what type of fault).
Some applications require the ability to run a program as soon as a fault occurs of continue running a program even through a fault condition.
In order to do this, a program must be classified as "Run Anytime". To define a program to be able to run during a fault or while the drive is
disabled, the "Run Anytime" check box must be selected in the Program view. Figure 141 shows an example of the "Run Anytime" check box
after it has been selected.
