FLX-3232 Installation Guide

DIGIB-EMT

Signal Characteristics
Wide-Band Infrared (IR)
Physical Characteristics
Material, Emitter Housing
Dimensions, Emitter Housing
Cable Length
Cable Connector
Shipping Weight
Other
Warranty
What's in the Box
Compatible Devices

DIGIB-EYE

Signal Characteristics
Wide-Band Infrared (IR)
Physical Characteristics
Material, Emitter Housing
Dimensions, Emitter Housing
Cable Length
Cable Connector
Shipping Weight
Other
Warranty
What's in the Box
Compatible Devices
34
Technical Specifications
30 KHz to 56 KHz at 5V DC reference
Deep red translucent plastic
6 mm x 9.5 mm x 15 mm (0.24 in. x 0.37 in. x 0.59 in.)
2 m (6.56 ft)
3.5 mm (1/8 in.) mono (TS) plug
0.5 lbs. (0.23kg)
2 years
(4) DIGIB-EMT
FLX-BI4, FLX-BO4, DIGI-HDE-S, DIGI-HDE-R, DIGI-HD60C-S, DIGI-HD60C-R,
DIGI-HD-IR3-S, DIGI-HD-IR3-R, DIGI-HD-IR3-WP-S, DIGI-HD-IR3-WP-R,
DIGI-HD-8X8, DIGI-HD-4X8, DIGI-HD-4X4, DIGI-HD-4X2
Technical Specifications
30 KHz to 56 KHz at 5V DC reference
Black plastic housing; smoke gray lens housing
13.5 mm x 9 mm x 29.5 mm (0.53 in. x 0.35 in. x 1.16 in.)
1 m (3.28 ft)
3.5 mm (1/8 in.) stereo (TRS) plug
0.5 lbs. (0.23kg)
2 years
(1) DIGIB-EYE (hardware not included)
FLX-BI4, FLX-BO4, DIGI-HDE-S, DIGI-HDE-R, DIGI-HD60C-S, DIGI-HD60C-R,
DIGI-HD-IR3-S, DIGI-HD-IR3-R, DIGI-HD-IR3-WP-S, DIGI-HD-IR3-WP-R
