FLX-DO4

I/O Connections
Single Link DVI Output
Supported Video
Output Signal Types
Video Compliance
EDID and DDC
DVI Signal Characteristics
Bandwidth
Gain
Resolution Range
Crosstalk
Input Level
Chassis and Environmental
Construction
Shipping Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Other
Warranty
Matrix Switcher Compatibility
Technical Specifications
Four (4) Female DVI 24+5
Single Link DVI-D up to 1920x1200
HDMI and HDCP
Actively Buffered; Supports DVI and HDMI standards
340 MHz (10.2 Gbps)
0 dB
640x480 – 1920x1200
< -50 dB at 5 KHz
TMDS 2.9V/3.3V
Plug-in card with keyed black metal plate
0.37 kg (0.81 lbs.)
0° to +40° C (+32° to +104° F)
20% to 90%, Non-condensing
-10° to +60° C (+14° to +140° F)
20% to 90%, Non-condensing
2 years
FLX-8X8A, FLX-3232, FLX-3232, FLX-3232
FLX-3232 Installation Guide
