FLX-RI4

I/O Connections
Analog Video Input
Supported Video
Input Signal Types
Output Scaling Resolutions
Analog Video Input Characteristics
Bandwidth
Gain
Resolution Range
Crosstalk
Input Coupling
Input Level
Chassis and Environmental
Construction
Shipping Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Included Accessories
FLX-RBOCA (2 ea)
FLX-RBOCB (2 ea)
Other
Warranty
HDMI Matrix Switcher Compatibility
Technical Specifications
Four (4) Female HD15
VGA-UXGA, RGBHV, RGsB, RsGsBs, Component Video, S-Video, &
Composite Video
XGA (1024x768), WXGA (1280x800), 720p (1280x720), and 1080p
(1920x1080)
340 MHz (10.2 Gbps)
0 dB
640x480 – 1920x1080
< -50 dB at 5 MHz
AC Coupling Only
0.5V – 2.0Vp-p
Plug-in card with keyed black metal plate
0.67 kg (1.36 lbs.)
0° to +40° C (+32° to +104° F)
20% to 90%, Non-condensing
-10° to +60° C (+14° to +140° F)
20% to 90%, Non-condensing
40 mm (15.75 in.) Male HD15 to three (3) Female RCA Connectors (Red,
Green, Blue)
40 mm (15.75 in.) Male HD15 to one (1) Female RCA Connector
(Yellow) and one (1) Female S-Video Connector
2 years
FLX-8X8A, FLX-3232, FLX-3232, FLX-3232
FLX-3232 Installation Guide
