HDCP Commands

Description
Turn HDCP Compliance off for input xx
Turn HDCP Compliance on for input xx
Example:
/%I/04:0.

FLX-RI4 Specific Commands

The input number values are dependent upon which slot the FLX-RI4 is inserted. If the input
card is in the first input card slot, the input number values range from 01 through 04. If the input
card is in the second input card slot, the input number values range from 05 through 08. xx is
the input number value.
Description
Set input xx to VGA input mode
When input xx is in VGA mode, auto adjusts the
input signal
Set input xx to component video input mode
Set input xx to S-video input mode
Set input xx to composite video input mode
Set input xx to scale to XGA output (1024x768)
Set input xx to scale to 720p output (1280x720)
Set input xx to scale to WXGA output (1280x800)
Set input xx to scale to 1080p output (1920x1080)
Set input xx to VGA input mode
Examples:
PTNI050622%.
PTNI050606%.
PTNI020623%.
Turn HDCP Compliance off for input 4
Set input 5 to VGA input mode
Auto adjust input 5 VGA source
Set input 2 to component video input mode
Command Response
/%I/xx:0. /%I/xx:0.<CR><LF>
/%I/xx:1. /%I/xx:1.<CR><LF>
Command
PTNIxx0622%.
PTNIxx0606%.
PTNIxx0623%.
PTNIxx0624%.
PTNIxx0625%.
PTNIxx0626%.
PTNIxx0627%.
PTNIxx0628%.
PTNIxx0629%.
PTNIxx0622%.
FLX-3232 Installation Guide
Response
xx0622%.<CR><LF>
xx0606%.<CR><LF>
xx0623%.<CR><LF>
xx0624%.<CR><LF>
xx0625%.<CR><LF>
xx0626%.<CR><LF>
xx0627%.<CR><LF>
xx0628%.<CR><LF>
xx0629%.<CR><LF>
xx0622%.<CR><LF>
