RS232 and TCP/IP Commands

RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None
TCP/IP Settings: User defined IP address, port 4001
There is either a period (.) or a semicolon (;) at the end of each command. These characters must
be present for the command to process correctly.
There are no spaces between any of the characters in the command string.
xx = Input Number (input 2 would be 02)
yy = Output Number (output 3 would be 03)
<CR> = Carriage return (Hex 0D)
<LF> = Line Feed (Hex 0A)

Routing Commands

Description
Route input xx to output yy
Route input xx to all outputs
Route inputs to corresponding outputs
Route input xx to multiple outputs yy
Number of outputs is unlimited; each output
must be separated by a comma (,)
Turn off all outputs
Turn off specific output yy
Output yy routing status
Routing status of all inputs.
Examples:
02All.
04$.
06B03.
03B02,08.
Route Video and Audio from input 2 to all outputs
Turn off Video and Audio for output 4
Route Video and Audio from input 6 to output 3
Route Video and Audio from input 3 to outputs 2 and 8
Command Response
xxByy. AV: xx->0yy<CR><LF>
xxAll. xx
All#. All Through.<CR><LF>
xxByy,yy. xxVyy,yy<CR><LF>
All$. All Closed.<CR><LF>
yy$. AV: yy Closed. <CR><LF>
Statusyy. V: xx->0yy<CR><LF>
Status. V: xx->0yy<CR><LF>
(Repeating sequence
starting with output 1,
output 2, etc.)
FLX-3232 Installation Guide
To All<CR><LF>
21
