FLX-3232 Installation Guide
Technical Specifications

FLX-3232 Chassis

I/O Connections
Supported Input Cards
Supported Output Cards
Input and Output Card Securing Mechanism
Control, Rear Panel
Control, Front Panel
Chassis and Environmental
Material
Dimensions
Rack Spacing
Shipping Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power, ESD, and Regulatory
Power Supply
Power Consumption
ESD Protection
Regulatory
Other
Warranty
Diagnostic Indicators
Included Accessories
26
Technical Specifications
FLX-BI4, FLX-DI4, FLX-HI4, FLX-RI4, FLX-HI4A
FLX-BO4, FLX-DO4, FLX-HO4, FLX-BO4A, FLX-HO4A
Thumbscrew
RS232 via DE-9, TCP/IP via 8P8C Connector
Push Button, IR
Black Painted Aluminum
483mm x 356mm x 222mm (19 in. x 14 in. x 8.75 in.)
5 RU
9.98 kg (22 lbs.)
0° to +40° C (+32° to +104° F)
20% to 90%, Non-condensing
-10° to +60° C (+14° to +140° F)
20% to 90%, Non-condensing
100-240VAC 50/60 Hz
280 watts Fully Populated
15kV
CE, RoHS
2 years
LCD output status and power LED
Installation Guide, IR Remote, RS232 Cable, Power Cable, Modular Metal
Blank (16 ea), Rubber Feet (4 ea) and Intelix Pocket Screwdriver.
