Stock connectors
i105-411
www.powercommander.com
Unplug this connector
PCIII connectors
Ground wire from PCIII
1
Remove the main seat and rear
solo seat cover.
2
Prop the front of the fuel tank
up.
3
Locate the connector in Fig. A.
Unplug this connector. This
connector is located on the left
hand side of the bike.
4
Plug the grey connectors from
the PCIII inline of the stock
connectors (Fig. B)
5
Attach the ground wire from the
PCIII to the negative side of the
battery (Fig. C).
2000-2001 Honda RC51 - PCIII USB - 2
