Amplifi er Specifi cations
Model Number
Connectors
Impedance (input/output)
Dimensions
Weight
Frequency
1
Passband Gain (nominal)
2
20 dB Bandwidth (nominal)
³Power output for single cell phone (uplink)
Power output for single received channel
(downlink)
4 Power output for multiple
received channels (downlink).
The maximum power is reduced by
the number of channels:
Noise Figure (typical)
Isolation
Power Requirements
Notes:
1. Nominal gain is the maximum gain at any frequency in the passband.
2. Nominal bandwidth is the difference between two frequencies that are adjacent to the passband where the amplifi cation is 20 dB
lower than the passband amplifi cation. One of the frequencies is lower than the passband and the other is higher.
3. The Manufacturer's rated output power of this equipment is for single carrier operation. For situations when multiple carrier
signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can
cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by
an attenuator at the output of the device.
4. The maximum power for 2 or more simultaneous signals will be reduced by 6 dB every time the number of signals is doubled.
800 MHz (uplink/downlink)
1900 MHz (uplink/downlink)
800 MHz (uplink/downlink)
1900 MHz (uplink/downlink)
Number of
channels
2
3
4
5
6
3301 East Deseret Drive, St. George UT 84790
For additional Technical Support visit
www.wilsonelectronics.com
Phone: 866-294-1660
800/1900 MHz Specifi cations
5 x 3.5 x 1.2 inch or 12.7 x 8.9 x 3 cm
824-894 MHz / 1850-1990 MHz
800 MHz
CDMA +33.0 dBm
GSM +34.3 dBm
EDGE +34.1 dBm
AMPS +30.1 dBm
800 MHz
CDMA +5.1 dBm
GSM +3.2 dBm
EDGE +3.2 dBm
AMPS +3.2 dBm
800 MHz
+1.0 dBm
-2.5 dBm
-5.0 dBm
-7.0 dBm
-8.5 dBm
uplink/downlink more than 50 dB
12 V, 2 A (subject to uplink power)
Wilson
®
Electronics, Inc.
Fax: 435-656-2432
Dual Band
811210
FME-Male
50 Ohms
1.03 lbs or 0.468 kg
26 dB / 26 dB
26 dB / 26 dB
53 MHz / 62 MHz
112 MHz / 110 MHz
1900 MHz
+29.3 dBm
+30.3 dBm
+30.2 dBm
1900 MHz
+6.8 dBm
+4.4 dBm
+4.6 dBm
Maximum Power
1900 MHz
+1.7 dBm
-1.8 dBm
-4.3 dBm
-6.3 dBm
-7.8 dBm
3.5 dB nominal
Part #110464 AIG SBMK 004 / 05.28.08
