Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer.
Installation Instructions for the Following Wilson Amplifier: SOHO Wireless Dual-Band Cellular/PCS Amplifier Model # 271245, Part # 801245 FCC ID: PWO8012SM IC: 4726A-8012SM The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.
Wilson Electronics manufactures a wide variety of antennas and accessories to help you customize your SOHO Wireless Dual-Band Amplifier for your specific application (see page 2).
Installing the Outside Antenna The antenna that communicates with the outside should be mounted on the outside of the building—this is the preferred location and will give the best performance. Alternatively, locating this antenna inside the building near a window will also work under certain conditions.
Installing the Inside Antenna The antenna that communicates with your inside or cellular data card should be installed in the center of where the signal needs to be amplified. Wilson’s magnet-mount, mini magnet-mount, dome and panel antennas will work well with the SOHO Wireless Amplifier.
Connect the outside antenna to the amplifier with 50-ohm or equivalent coax cable (available in different lengths from Wilson Electronics). Place the inside antenna in the center of the area needing the amplified signal. It is important to have at least 20 feet of separation between the inside and outside antennas.
Powering up a Wilson Amplifier IMPORTANT! Ensure that all insides and cellular data cards within 20 feet of the inside antenna are turned off. 2. To verify proper installation of the amplifier and antennas, make sure that the distance between the inside and outside antennas is a minimum of 20 feet. 3.
Understanding the Amplifier Lights The power light PWR will turn green when the amplifier is successfully powered up. When the 800 MHz or 1900 MHz lights are lit green, the amplifier is amplifying the outside signal. If one or both frequency lights turn red, the amplifier is oscillating.
Warnings and Recommendations Warning: A Yagi antenna must always be located so the back or side points to the inside antenna. Never point the front of the Yagi antenna toward the inside antenna – oscillation will result, causing amber light and gain reduction. Warning: Connecting the amplifier directly to the inside with use of an adapter will damage the inside.
About Wilson Electronics Wilson Electronics, Inc. has been a leader in the wireless communications industry for nearly 40 years. The company designs and manufactures amplifiers, antennas and related components that significantly improve cellular telephone signal reception and transmission in a wide variety of applications, both mobile and in-building.
Amplifier Specifications Dual Band 800/1900 MHz Specifications Model Number 271245 Connectors FME-Male Impedance (input/output) 50 ohms Dimensions 5.6 x 3.6 x 1.7 inch or 14.2 x 9.1 x 4.4 cm Weight 1.44 lbs or 0.65 kg Frequency 824-894 MHz / 1850-1990 MHz...
