Page 1: Table Of Contents
Amplifier Amplifier Installation stallatio stallat Guide In-Building Wireless Amplifi er Contents: Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · 1 Antenna Options and Accessories · · · · · · · · · · · · · · · Before Getting Started / How It Works ·... - Page 2 Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer.
-
Page 3: Antenna Options And Accessories
Installation Instructions for the Following Wilson Amplifi ers: In-Building Wireless Cellular Smart Technology™ 50 dB Amplifi er Model # 801105 FCC ID: PWO8011SB IC: 4726A-8011SB In-Building Wireless Cellular Smart Technology™ 60 dB Amplifi er Model # 801106, Part # 801108, Part # 801110... -
Page 4: Before Getting Started / How It Works
Before Getting Started This guide will help you properly install Wilson’s In-Building Wireless Smart Technology™ Amplifi ers. It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment. -
Page 5: Installation Overview
Position the amplifi er in a well-ventilated location near a power outlet. Attach the outside and inside antennas to the amplifi er using Wilson 400 low loss coax cable (available from Wilson Electronics). STEP 4 Power up the Amplifi er... -
Page 6: Installing A Wilson Outside Antenna
Installing a Wilson Outside Antenna Select a location on the roof of the building to install the outside antenna, using a cell phone in test mode to fi nd the strongest signal from the cell tower. RF Signal Cell Tower Yagi External Antenna Warning: Never point the front of the Yagi antenna toward... -
Page 7: Installing A Wilson Inside Antenna
Installing a Wilson Inside Antenna Select a suitable location for the inside antenna, preferably in the center of where the signal needs to be amplifi ed. To determine signal strength and coverage distance, refer to page 12 of this installation guide. Follow the specifi... -
Page 8: Installing A Wilson Amplifi Er
Connect the outside antenna to the amplifi er with Wilson 400 low loss coax cable (available from Wilson Electronics). Place the inside antenna in the center of the area needing the amplifi ed signal. It is important to have at least 50 feet of separation between the inside and outside antennas for the 50 dB amplifi... -
Page 9: Powering Up A Wilson Amplifi Er
Powering up a Wilson Amplifi er IMPORTANT! Ensure that all cell phones and cellular data cards within 50 feet of the inside antenna are turned off. 2. To verify proper installation of the amplifi er and antennas, make sure that the distance between the inside and outside antennas is a minimum of 50 feet for the 50 dB amplifi... -
Page 10: Understanding The Amplifi Er Lights
Understanding the Amplifi er Lights If your amplifi er has this light confi guration refer to the instructions below. The amplifi er is equipped with sensitive electronics designed to detect amplifi er oscillation or cell phone overload, both of which can hamper amplifi er performance. The amplifi... -
Page 11: Understanding The Amplifi Er Lights
Understanding the Amplifi er Lights If your amplifi er has this light confi guration refer to the instructions below. The amplifi er is equipped with sensitive electronics designed to detect amplifi er oscillation or cell phone overload, both of which can hamper amplifi er performance. The amplifi... -
Page 12: Understanding The Amplifi Er Lights
Understanding the Amplifi er Lights Wilson ® Electronics, Inc. Electronics, Inc. If your amplifi er has this light T T M M confi guration refer to the instructions below. The amplifi er is equipped with sensitive electronics designed to detect amplifi er oscillation or cell phone overload, both of which can hamper amplifi... -
Page 13: Warnings And Recommendations
Warnings and Recommendations Warning: The Yagi antenna must always be located so the back or side points to the inside antenna. Never point the front of the Yagi antenna toward the inside antenna – oscillation will result, causing amber light and gain reduction. Warning: The outside antenna must be installed on an outdoor permanent structure with a separation of at least 20 feet from all persons... -
Page 14: Factor Conversions
Factor Conversions Using the table below, fi nd and circle the appropriate decibel (dB) numbers that correspond to the equipment in your particular system. Be sure to choose your numbers from the appropriate frequency column based on the service you receive (iDEN, Cellular or PCS). - Page 16 In-Building Wireless Amplifi er Specifi cations (GSM & Cellular) Model/Part GSM only GSM only Cellular Cellular Cellular Cellular Cellular Number # 801170 # 801370 # 801105 # 801106 #801108 #801110 #801165 Not for sale in the U.S. or Canada Frequency Uplink 824-849 1850-1910 824-849 824-849...
