Wilson Electronics 271245 Installation Manual

Mobile wireless dual-band cellular/ pcs amplifier
Hide thumbs Also See for 271245:

Advertisement

Amplifier
Amplifier
Installation
Installation
Installation
Guide
Contents:
Guarantee and Warranty ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  1
How it Works  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   2
Before Getting Started ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   3
Installing a Wilson Outside Antenna  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   4
Installing a Wilson Amplifi  er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  5
Installing a Wilson Inside Antenna (Wireless)  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  6
Installing a Wilson Inside Antenna (Attached)  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  7
Powering Up a Wilson Amplifi  er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  8
Warnings and Recommendations  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  9
Understanding the Amplifi  er Lights  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  10
Amplifi  er Specifi  cations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  Back Cover
Mobile Wireless
Dual­Band
Cellular / PCS
Amplifi  er
!
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplifi  er.

Advertisement

Table of Contents
loading

Summary of Contents for Wilson Electronics 271245

  • Page 1: Table Of Contents

    Amplifier Amplifier Installation Installation Installation Guide Mobile Wireless  Dual­Band  Cellular / PCS  Amplifi  er  Contents:  Guarantee and Warranty ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  1  How it Works  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   2  Before Getting Started ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   3  Installing a Wilson Outside Antenna  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙   4  Installing a Wilson Amplifi  er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  5  Installing a Wilson Inside Antenna (Wireless)  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  6  Installing a Wilson Inside Antenna (Attached)  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  7  Powering Up a Wilson Amplifi  er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  8  Warnings and Recommendations  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  9  Understanding the Amplifi  er Lights  ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  10  Amplifi  er Specifi  cations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙  Back Cover  Warning: This manual contains  important safety and operating information.  Please read and follow the instructions ...
  • Page 2: Guarantee And Warranty

    30­Day Money­Back Guarantee  All  Wilson  Electronics  products  are  protected  by  Wilson’s  30­day  money­back  guarantee.    If  for  any  reason  the  performance  of  any  product  is  not  acceptable,  simply return the product directly to the reseller with a dated proof of purchase.  1­Year Warranty  Wilson  Electronics  amplifi  ers  are  warranted  for  one  (1)  year  against  defects  in  workmanship and / or materials.  Warranty cases may be resolved by returning the ...
  • Page 3: How It Works

    Installation Instructions for the Following Wilson Amplifi  er:  Mobile Wireless Dual­Band Amplifi  er  Model # 271245, Part # 801201  FCC ID: PWO8012SM   IC: 4726A­8012SM  The term “IC” before the radio certifi  cation number only signifi  es that Industry Canada  technical specifi  cations were met.  Inside this Package  Low­profi  le  Universal  Wireless  DC plug­in  antenna  Connector  amplifi  er  power supply  (Option A ­ see p. 6)  (Option B ­ see p. 7)  How it Works  Your new Wilson amplifi  er has been carefully engineered to signifi  cantly improve the  performance of your cell phone or cellular data card in mobile applications.  Together with  an outside antenna (sold separately), the amplifi  er’s state­of­the­art technology is designed  to increase your signal up to 10 times, reduce disconnects and dropouts, and increase data  communication rates needed for 3G technologies.  The outside antenna will collect the cell tower signal and send it through the cable to the  amplifi  er.  The signal is then boosted and sent through the inside antenna or to the universal  connector, depending on your application.  Your cell phone or data card then communicates  with the improved signal.  When the cell phone or data card transmits, the signal goes  through the inside antenna or the universal connector, is boosted by the amplifi  er and ...
  • Page 4: Before Getting Started

    Before Getting Started  This guide will help you properly install Wilson’s dual­band, mobile wireless amplifi  er. It is  important to read through all of the installation steps for your particular application  prior to installing any equipment. Read through the instructions, visualize where all the  equipment will need to be installed and do a soft installation before mounting any equipment.  If you do not understand the instructions in full, seek professional help, or contact Wilson  Technical Support at 866­294­1660.  Installation Diagram  Inside Antenna  !  Warning: In a wireless installation,  Outside  do not plug the amplifi  er directly into the  Antenna  cell phone or data card using an antenna  adapter.  It will damage the amplifi  er.  Cell Phone  PDA  Notebook  Inside  Antenna  DC Power  Supply  Amplifi  er  Installation Diagram  !  Universal Connector Warning: In a wireless installation,  Outside  do not plug the amplifi  er directly into the  Antenna  cell phone or data card using an antenna  adapter.  It will damage the amplifi  er.  Cell Phone, PDA or  Notebook with ...
  • Page 5: Installing A Wilson Outside Antenna

    Installing a Wilson Outside Antenna  To receive the best cell signal, select a location in the center of the vehicle’s roof 12 inches  away from any other antennas and free of obstructions.  Follow the specifi  c antenna installation instructions included with the outside antenna (sold  separately).  !  Warning: Do not use any type of glass­  mount antenna with this amplifi  er.  The outside  and inside antennas must be shielded from  each other to prevent oscillation.  The outside antenna must be installed  vertically.  Signal performance will be  degraded if the antenna is not vertical.  Optional Magnet­  The antenna cable may be run through the  Mount Antenna  door to the amplifi  er.  Shown  Part #301103  Warning: The outside antenna must  have a separation of at least 10 inches from all  persons during normal operation.  For a more professional­looking installation,  Carefully  Run Cable  the antenna cable may be run under the  Pull Down  Under  door seal.  Carefully pull down the door  Door Seal  Seal  seal.  Run the cable through the seal  and push the seal back into place.  This  prevents constant wear and tear on the  cable as the door opens and closes.  The antenna cable is small enough to easily  tuck under the door seal or plastic molding.  Tuck Cable ...
  • Page 6: Installing A Wilson Amplifi  Er

    Installing a Wilson Amplifi  er  !  Warning: Do not plug in the DC power  supply until the outside and inside antenna  cables are attached to the amplifi  er.  Select a location to install the amplifi  er that  is away from excessive heat, direct sunlight  or moisture and that has proper ventilation.  Recommended installation locations are: · Under the seat · In the trunk · Under the dash  Run the cable from the outside antenna and  attach it to the FME­Male connector labeled  “outside antenna” on the amplifi  er.  Attach the inside antenna cable to the FME­  Male connector labeled “inside antenna” on  the amplifi  er. Wilson offers two options of improved signal  inside a vehicle:  Option A (Wireless) ­ offers the  convenience of no physical connection to  the cell phone or cellular data card.  Option B (Attached) ­ places the universal  connector directly on the cell phone or  cellular data card for maximum signal  performance.  5 ...
  • Page 7: Installing A Wilson Inside Antenna (Wireless)

    Option A (Wireless) Installing a Wilson Inside Antenna Install the low­profi  le inside antenna 8­12  inches from where the cell phone or cellular  Low­profi  le  data card will be used.  Antenna  Amplifi  er  !  Warning: Do not install the low­profi  le  antenna within four inches of metal.  (Metal  found inside the vehicle’s seat will not affect  the antenna’s performance.)  Place the inside antenna on the side of the  driver’s seat for maximum performance.  Install the inside antenna at least eight  inches, but not more than 12 inches, from  where the cell phone or cellular data card  will be used.  Install the inside antenna at the same angle  as the cell phone when held in use, or place  next to the laptop’s cellular data card. This  will maximize the signal strength.  For a more professional­looking installation,  the low­profi  le antenna may be slid under  the seat cover or leather, high on the  driver’s seat.  Warning: The inside antenna must  be installed with a separation of at least  eight inches from all persons and must not  be located in conjunction with any other  antenna or amplifi  er.  6 ...
  • Page 8: Installing A Wilson Inside Antenna (Attached)

    Option B (Attached) Installing a Wilson Universal Connector Amplifi  er  Universal  Connector  The universal connector must be placed  directly on the cell phone or cellular data  card to work properly.  Attach the universal  connector to the cell phone or cellular data  card with the VELCRO  ®  included in the  package.  IMPORTANT: The adhesive of the  gray Velcro patch that adheres to the back  of your phone needs time to “cure.”  For best  results, do not use the Velcro connection for  a minimum of 24 hours after application.  The universal connector included in the  package is long enough to reach the  amplifi  er location.  This allows for ease and  convenience of use.  To adjust the universal connector for the  best signal, go to a weak signal location  where your cell phone registers only 1­2 bars  without the universal connector connected.  Then, attach the universal connector to  the phone and you should see a signal  improvement of 2 or more bars.  NOTE: Many phones take up to 20 seconds  to reset the bar indicator.  Cellular data card To maximize performance, attach the  universal connector as close as possible to the original antenna on your cell phone or cellular  data card.  For cell phones with an internal antenna,  place the universal connector on the back, ...
  • Page 9: Powering Up A Wilson Amplifi  Er

    Powering up a Wilson Amplifi  er  Make sure both the outside and inside  antenna cables are connected before  powering up the amplifi  er.  Connect the power cable from the DC  plug­in power supply to the amplifi  er  marked “Power” and insert the large end  into DC power socket (the cigarette lighter  outlet.)  Warning: Use only the power  Carefully insert the power cable.  supply provided in this package.  The  power supply must be 6 V DC.  The amplifi  er may remain on all the time.  However,  leaving the amplifi  er on in a  vehicle when it is not running can discharge  the battery in a day or two.  A good option is to power the amplifi  er  through the ignition switch so the amplifi  er  IMPORTANT:  Do not power up the ampli­  is turned on and off with the vehicle.  fi  er unless antenna cables are attached to  amplifi  er.  NOTE:  The aluminum casing of a Wilson amplifi  er will adjust very quickly to the ambient  temperature of its environment. For example, in the summer, when the inside of a car can  reach 140 degrees Fahrenheit, the amplifi  er temperature may be 150 degrees or higher.  The casing will be hot to the touch, similar to a metal door handle or a steering wheel. Such  high temperatures will not damage the amplifi  er, nor do they pose a fi  re risk to the vehicle.  As recommended in these instructions, install the amplifi...
  • Page 10: Warnings And Recommendations

    Warnings and Recommendations  Warning:   In a wireless installation, do not plug the amplifi  er directly into  the cell phone or cellular data card using an antenna adapter.  It  will damage the cell phone or cellular data card.  Warning:  Do not plug in the DC power supply until the outside and inside  antenna cables are attached to the amplifi  er.  Warning:  RF Safety: The inside antenna must be installed with a  separation of at least eight inches from all persons and must not  be located in conjunction with any other antenna or amplifi  er.  Warning:  RF Safety: The outside antenna must be installed with a  separation of at least 10 inches from any of the vehicle’s  occupants or nearby persons and must not be located or  operating in conjunction with any other antenna or amplifi  er.  All  roof­mount antennas should be centrally located on the roof of  the vehicle.  Mirror­mount antennas should be at least six inches  from the ground and leave at least 20 inches of separation from  any persons near or around the vehicle.  Use of this cellular  amplifi  er with an antenna gain higher than 6.12 dBi is in violation  of FCC regulations for which the offender is fully liable.  All  Wilson mobile antennas are 6.12 dBi or less.  Separation of inside and outside antennas is very important.  The metal  roof of the vehicle acts as a barrier and helps shield the two antennas from  each other, preventing oscillation.  If the vehicle has a sunroof, it is important to separate the inside and outside antennas  by at least fi  ve feet. This prevents the amplifi  er from overloading or oscillating.  Distance between antennas  through a sunroof must be  5 feet or more. 9 ...
  • Page 11: Understanding The Amplifi  Er Lights

    Understanding the Amplifi  er Lights  The power light PWR will turn green  when the amplifi  er is successfully  powered up.  When the 800 MHz or  1900 MHz lights are lit green, the  amplifi  er is amplifying the outside  signal.  If one or both frequency lights turn  red, oscillation is occurring and the  amplifi  er has powered down.  The  outside antenna needs to be moved  farther from the inside antenna.  Move  the outside antenna on the roof of  the car to the rear of the car, but at  least 8­12 inches from the rear or  side windows.  Remove power from  the amplifi  er and reinstall power ­ this  resets the amplifi  er.  If the lights are now green, the  oscillation has stopped and the  amplifi  er is working.  If the red light is  still on, move the antenna farther away  and repeat the process.  Always use a magnet­mount or roof­  mount antenna.  Do not use a glass­  mount antenna, as oscillation may  cause  continuous shut­down of the  amplifi  er.  An amber light in either the 800  MHz or 1900 MHz position indicates  overload from the cell site.  The  amplifi  er has temporarily shut down  and will automatically reset.
  • Page 12: Amplifi  Er Specifi  Cations

    Amplifi  er Specifi  cations  Dual Band  800/1900 MHz Specifi  cations  Model Number / Part Number  271245 / 801201  Connectors  FME­Male  Impedance (input/output)  50 ohms  Dimensions  5.6 x 3.6 x 1.7 inch or 14.2 x 9.1 x 4.4 cm  Weight  1.44 lbs or 0.65 kg  Frequency  824­894 MHz / 1850­1990 MHz  1  Passband Gain (nominal)  800 MHz  50 dB  1900 MHz  60 dB  2  20 dB Bandwidth (nominal)  800 MHz (uplink/downlink)  53.5 MHz / 47.7 MHz  1900 MHz (uplink/downlink)  86 MHz / 83 MHz  Power output for single cell phone (uplink)  800 MHz  1900 MHz  CDMA  +30.9 dBm  +30.5 dBm  GSM  +30.0 dBm  +29.7 dBm  EDGE ...
