Wilson Electronics 801105 Installation Manual
  1. Manuals
  2. Brands
  3. Wilson Electronics Manuals
  4. Amplifier
  5. 801105
  6. Installation manual

Wilson Electronics 801105 Installation Manual

Hide thumbs Also See for 801105:

Advertisement

Table of Contents

Amplifier
Installation
Guide
Contents:
Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · · ·
Antenna Options and Accessories · · · · · · · · · · · · · · · · · 2
Before Getting Started / How It Works · · · · · · · · · · · · · · 3
Quick Start Guide · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
Installing a Wilson Outside Antenna · · · · · · · · · · · · · · · · 5
Installing a Wilson Inside Antenna · · · · · · · · · · · · · · · · · 6
Installing a Wilson Amplifier · · · · · · · · · · · · · · · · · · · · · · 7
Powering Up a Wilson Amplifier · · · · · · · · · · · · · · · · · · · 8
Understanding the Amplifier Lights · · · · · · · · · · · · · · · · · 9
Troubleshooting · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
Cell Phone Overload Protection · · · · · · · · · · · · · · · · · · 11
Warnings and Recommendations · · · · · · · · · · · · · · · · · 12
Amplifier Specifications · · · · · · · · · · · · · · · · · · Back Cover
In-Building
Wireless
Amplifier
MODEL# 801105
MODEL# 801106
MODEL# 801306
MODEL# 804005
MODEL# 804006
!
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplifier.
1
Wilson
®
Electronics, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 801105 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wilson Electronics 801105

Summary of Contents for Wilson Electronics 801105

  • Page 1: Table Of Contents

    Amplifier Installation Guide In-Building Wireless Amplifier MODEL# 801105 MODEL# 801106 MODEL# 801306 MODEL# 804005 MODEL# 804006 Contents: Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · · ·...
  • Page 2 Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer.

  • Page 3: Antenna Options And Accessories

    Installation Instructions for the Following Wilson Amplifiers: In-Building Wireless Cellular Smart Technology™ 50 dB Amplifier Model # 801105, Part # 801107, Part # 801108 FCC ID: PWO8011SB IC: 4726A-8011SB In-Building Wireless Cellular Smart Technology™ 60 dB Amplifier Model # 801106, Part # 801109, Part # 801110...

  • Page 4: Before Getting Started / How It Works

    Before Getting Started This guide will help you properly install Wilson’s In-Building Wireless Smart Technology™ Amplifiers. It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment.

  • Page 5: Quick Start Guide

    Position the amplifier in a well-ventilated location near a power outlet. Attach the outside and inside antennas to the amplifier using 9913 or equivalent coax cable (available from Wilson Electronics). STEP 4 Power up the Amplifier IMPORTANT! Before connecting the power supply, ensure that both the inside and outside antenna cables are connected.

  • Page 6: Installing A Wilson Outside Antenna

    Installing a Wilson Outside Antenna Select a location on the roof of the building to install the outside antenna, using a cell phone in test mode to find the strongest signal from the cell tower. For test mode help, visit www.wilsonelectronics.com or call Technical Support at 866-294-1660.

  • Page 7: Installing A Wilson Inside Antenna

    Installing a Wilson Inside Antenna Select a suitable location for the inside antenna, preferably in the center of where the signal needs to be amplified. To determine signal strength and coverage distance, refer to page 11 of this installation guide. Follow the specific antenna installation instructions included with the inside antenna.

  • Page 8: Installing A Wilson Amplifier

    Connect the outside antenna to the amplifier with 9913 or equivalent coax cable (available from Wilson Electronics). Place the inside antenna in the center of the area needing the amplified signal. It is important to have at least 40 feet of...

  • Page 9: Powering Up A Wilson Amplifier

    Powering up a Wilson Amplifier IMPORTANT! Ensure that all cell phones and cellular data cards within 50 feet of the inside antenna are turned off. 2. To verify proper installation of the amplifier and antennas, make sure that the distance between the inside and outside antennas is a minimum of 40 feet for the 50 dB amplifier, 50 feet of separation distance for the 60 dB PCS amplifier, and 65 feet for the 60 dB cellular amplifier.

  • Page 10: Understanding The Amplifier Lights

    Understanding the Amplifier Lights The amplifier is equipped with sensitive electronics designed to detect amplifier oscillation or cell phone overload, both of which can hamper amplifier performance. The amplifier is designed to automatically reduce gain or, if necessary, shut down to prevent or compensate for these conditions.

  • Page 11: Troubleshooting

    Troubleshooting If light A is amber, this indicates the amplifier is working, but at reduced performance (gain level). Increase the separation distance between the inside and outside antennas, reset the amplifier by disconnecting and reconnecting the power supply, then check to ensure that light A is green.

  • Page 12: Cell Phone Overload Protection

    Cell Phone Overload Protection If the cell phone is too close to the inside antenna when making a call, it can overload the amplifier. To prevent such overload, the amplifier is equipped with Automatic Gain Control, which reduces gain. (Gain is indicated by green lights in the B, C and D positions.) One or more of these lights may go out, indicating gain cutback.

  • Page 13: Warnings And Recommendations

    Warnings and Recommendations Warning: The Yagi antenna must always be located so the back or side points to the inside antenna. Never point the front of the Yagi antenna toward the inside antenna – oscillation will result, causing amber light and gain reduction. Warning: The outside antenna must be installed on an outdoor permanent structure with a separation of at least 20 feet from all persons during...
  • Page 14 Factor Conversions Using the table below, find and circle the appropriate decibel (dB) numbers that correspond to the equipment in your particular system. Be sure to choose your numbers from the appropriate frequency column, based on the service you receive (iDEN, Cellular or PCS). Frequency iDEN Cellular...
  • Page 16 AIG IBW 028 / 11.21.06...

This manual is also suitable for:

801106804006804005801306

Table of Contents
