4.3.5 Drive Back

Note: the function Drive Back is only active, if a pinch protection system
(ISP, switches or pinch protection strips) is available and activated in
software!
After a safety function is triggered by ISP, the desktop automatically moves a defined
distance in the opposite direction. This immediately prevents any possible risk of
pinching.
Danger: in spite of ISP being in place, there may still be a risk of
pinching in exceptional cases, as it is not only the control unit, but also
the interaction between all the components in the electric height-
adjustable desk that is responsible for cutting out the motor. In addition,
the mechanical components, motor and ambient conditions all affect cut-
out sensitivity.
As the control unit manufacturer, LOGICDATA does not have an effect
on this residual risk and cannot therefore accept any liability.
Please follow the safety instructions in the manual and treat our product
with due care.

4.3.6 Anti-Pinch configuration

If the pinch protection device ACS-CB-SENS is attached to the COMPACT, the risk
of pinches is decreased. To activate the ACS-CB-SENS, go on as shown below:
1.
2.
3.
4.
5.
Possible situations:
• An ACS-CB-SENS is attached to the COMPACT
• An ACS-CB-SENS is attached to the COMPACT
again after an error.
• First use of the COMPACT in combination with
ACS-CB-SENS
The error code E71 is shown on the display.
Be sure that the ACS-CB-SENS is attached to the
COMPACT properly.
Disconnect the mains supply of the COMPACT and
wait at least 5 seconds.
Connect the mains supply of the COMPACT again.
