4. Operating the COMPACT control unit

To ensure safe operation of the COMPACT control unit, please observe the following
safety instructions:
Note: in case of a mains power breakdown or if the power cord is
plugged off during the movement of the drives, a manual reset of the
COMPACT may be necessary!
Caution: keep children away from electric height-adjustable desks,
control units and handswitches. There is risk of injury and electric shock.
Caution: unplug the power cord during a thunderstorm or if you do not
intend to use the desk for a longer period. The control unit might
otherwise be damaged by power surges.

4.1 Basic functions

Note: the COMPACT control unit offers an extensive range of functions.
The availability of some functions depends however on the handswitch
used.
This section describes the basic functions available with every
handswitch designed for use with COMPACT control units.
Note: the 2 basic functions upward and downward movement are
available for both motorgroups separately. Please read the manual of the
used handswitch to see which buttons are linked to which motor group!

4.1.1 Upward desktop movement

This function enables you to adjust the desktop upwards. To change its position,
proceed as follows:
Press the desktop up key.
Keep pressing the key until the required desktop height is reached.
Note: the desktop will continue moving upwards until you release the key
or the maximum height is reached.
Page 16 / 43
