5. Technical data

General
Supply voltage
Standby power, primary (typical)
Efficiency factor (typical)
Operating voltage for internal and external
electronics and Hall sensors
Precision of Motor current measurement
@ 100% Output Voltage and 4-8A per Motor
Ambient temperature
Relative humidity (for operation)
Storage and transport temperature
Relative humidity (for storage)
Protection class (with earth terminal)
Power cord (length)
Dimensions (L x B x H) [mm]
Tolerances
COMPACT-3
Output Power and sum currents for all motor
channels
Max. current per motor channel
Weight (typical)
EU: 207-254,4V / 50Hz
US: 90-127V / 50-60Hz
<0.6W
83% @ 300W input power
5VDC ±10% 250mA
±20%
Other cases Contact LOGICDATA
0-30° C
5-85% (non condensing)
-40-85° C
5-90% (non condensing)
I
3m ± 50mm
264 x 103 x 37
according to DIN ISO 2768-1 c
Hi Power cycle:
20s UP:
20s DOWN: 6,5A@33V
Pause:
Normal cycle 1/9:
30s UP:
30s DOWN: 6,5A@33V
Pause:
Normal cycle 2/18:
2min move: 6,5A@33V
Pause:
8A per motor channel
Maximum sum current restricted,
values shown above
598g
Page 30 / 43
17,5A@20V 350W
214,5W
9min
14A@24V 336W
214,5W
9min
214,5W
18min
