6.2 Error messages on the handswitch display

The display reads HOT.
Cause
The COMPACT control unit is fitted
with overheating
Overheating has caused it to stop
the control unit.
The display reads E + an error code.
Cause
There is an internal fault in the
COMPACT control unit.
Code Description
00 Internal Error Channel 1
01 Internal Error Channel 2
02 Internal Error Channel 3
12 Defect Channel 1
13 Defect Channel 2
14 Defect Channel 3
24 Overcurrent motor M1
25 Overcurrent motor M2
26 Overcurrent motor M3
48 Overcurrent motor group 1
49 Overcurrent motor group 2
60 Collision protection
62 Overcurrent control unit
Note: the COMPACT can be parameterized so that a manual reset (see
page 20) must be carried out after an overcurrent error (E24, E25, E26,
E48, E49 and E62).
Remedy
Wait until the control unit has cooled down
protection. and HOT is no longer displayed. The
COMPACT control unit is then operational
again.
Remedy
Proceed as indicated in the following error
list.
Remedy
Unplug power cord and contact the
customer service.
Unplug the control unit.
Fix the external short circuit.
Plug in the correct motor to the motor
socket that shows the error.
Start the control unit again.
Remove jammed objects from the driving
area.
Desk might be overloaded
from desktop.
Contact customer service.
Page 33 / 43
Or
remove load
