1.5 ISP (Intelligent System Protection)

ISP is an electronic state-of-the-art protection system developed by LOGICDATA. It
also substantially reduces the risk of fingers being trapped or pinched.
Danger: in spite of ISP being in place, there may still be a risk of
pinching in exceptional cases, as it is not only the control unit, but also
the interaction between the mechanical and electronic systems that is
responsible for cutting out the motor. In addition, the mechanical
components, motor and ambient conditions all affect cut-out sensitivity.
As the control unit manufacturer, LOGICDATA cannot therefore
eliminate this residual risk completely or accept any liability.
Note: the ISP-sensitivity and the ISP-cutoff value depend on the whole
system (mechanical and electrical components). To evaluate the ISP-
capability of a height adjustable table, please contact LOGICDATA!
Please note the following for maximizing ISP functionality:
To ensure the best possible pinch protection, a mechanical brake must be fitted that
is applied when the electric height-adjustable desk moves down.
Note: without a mechanical brake, cut-out sensitivity may be reduced
under load. However, if there is no load on the desktop, ISP will function
properly even without a brake.
Note: as soon as ISP has stopped the electric height-adjustable desk
from moving, you can then only adjust the desktop in the opposite
direction (the safety feature initially prevents you from adjusting the desk
in the same direction as triggered it).
