Go Power! GP-SW2000, GP-SW1000 and GP-SW600

3. Name and main function

3.1 Front view GP-SW2000:
a) On /Off b) Ventilation
e) Status Level f) Frequency
a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
Leave in REMOTE position when using optional remote.
b) Ventilation Ports:
Do not obstruct, allow at least one inch for airflow.
c) Input Level:
Displays input voltage. Green indicates normal battery level, yellow indicates mid to
low battery level and red indicates under voltage.
d) Load Level:
Displays AC load watts. Green indicates normal operation, yellow indicates mid to
high operation and red indicates overload levels.
e) Status Level:
Displays operating condition. Green indicates normal, flashing green every second
indicates Power Saving mode, and red indicates a Fault. See Section 5 for Power
Saving and LED variations in Fault mode.
f) Frequency:
Typical North American setting is 60 Hz. Set dip switch S4 to "0" for 50 Hz and "1" for
60 Hz.
g) Power Saving:
Puts inverter to sleep until a load is present.
h) Strain Relief Clamp:
Provides strain relief for Hard Wire AC Output option
i) AC Outlet: Ground Fault Protected (GFCI)
Outlet sockets available: North America
Inverter Owner's Manual
c) Input Level d) Load Level
g) Power Saving h) Strain Relief Clamp
i) AC Outlet
5
