i126-411
www.powercommander.com
Unplug this connector
PCIII connectors
Stock connectors
PCIII harness
1
Remove the main seat.
2
Remove the front two fuel tank
mounting bolts.
3
Prop the front of the fuel tank
up.
4
Locate the throttle body wiring
harness connector (Fig. A). This
connector is located on the right
hand side of the bike under the
right, rear corner of the air box.
5
Unplug the connector shown in
Fig. A.
6
Plug the connectors from the
PCIII in-line of the stock wiring
harness (Fig. B).
7
Route the PCIII wiring along the
inside of the frame towards the
rear of the bike (Fig. C).
2006-2007 Honda VFR800 - PCIII USB - 2
