6

TROUBLESHOOTING

6-1 TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE
LEDs are not
illuminated. Reversed battery polarity.
(transmitter/receiver)
Low battery indicator
blinks even though
the battery has Reversed battery polarity.
been inserted.
(transmitter/receiver)
Reflection from the floor or wall.
Alarm is not
output.
Beam has not been blocked.
Channels of transmitter
and receiver are different.
Alarm is kept Multiple photoelectric
detector for long distance
output.
or beam stacking applications.
Optical alignment was not
performed properly.
Batteries are going Tamper button has not
flat too quickly. performed properly.
Frost, snow or
Optical alignment not
heavy rain causes
optimized.
false alarm.
Improper output
The wiring is incorrect.
Screws between the
chassis and the back box
are loose.
Wall tamper does
not activate.
The waterproof packing on
back box is misplaced.
7

DIMENSIONS

7-1 DIMENSIONS
138 (5.4)
CORRECTIVE ACTION
Check the battery polarity.
Check the battery polarity.
Align beams away from the
floor or wall.
Block all four beams.
Set the same channel to
both transmitter and receiver.
Set channels 1-3 or 2-4 or
1-4.
See "4-2 OPTICAL
ALIGNMENT" on Page 9.
Set the cover or tamper
lock plate properly.
See "4-2 OPTICAL
ALIGNMENT" on Page 9
and make realignment.
Make correct wiring.
Tighten screws completely.
Remove chassis from the
back box and align the
waterproof packing onto
the chassis.
Unit: mm (inch)
-11-
8

SPECIFICATIONS

8-1 SPECIFICATIONS
Model
Maximum detection range
Maximum arrival distance
Detection method
Selectable beam frequency
Interruption time
Power source
Current draw
Battery life
*
**
Alarm output
Alarm period
D.Q output
Output
Low battery
output
Tamper output
(cover, back box,
main unit)
Alarm indicator
(Receiver)
Level indicator
(Receiver)
Indicator
Power indicator
(Transmitter)
Low battery indicator
Operating temperature
Operating humidity
Alignment angle
Dimension
Weight
International protection
Specifications and design are subject to change without prior notice.
* The value is based on the condition that it is used within the
ambient temperature range of 20 to 25°C. (LSH-20 x2 pcs)
** Using batteries other than those recommended may shorten the battery life.
NOTE
These units are designed to detect an intruder and activate
an alarm control panel. Being only a part of a complete
system, we cannot accept responsibility for any damages
or other consequences resulting from an intrusion.
These products conform to the EMC Directive 2004/108/EC.
SL-350QFR SL-350QNR
100 m/350 ft.
1000 m/3500 ft.
Quad infrared beam interruption detection
4 channels
Variable between 50/100/250/500 ms
(4 steps)
Recommend: 3.6 V, 13.0 Ah
LSH20 lithium batteries manufactured by SAFT
Operating range: 3.2 V - 4.0 V litium batteries
Transmitter: 2 or 4 units, Receiver: 2 or 4 units
745 μA
Transmitter: 420 μA + Receiver: 325 μA
(at 25°C, 3.6 VDC)
Transmitter: Approx. 4 years
Receiver: Approx. 5 years
Form C-Solid State Switch: 3.6 VDC, 0.01 A
2 sec (±1) (Nominal)
Form C-Solid State Switch: 3.6 VDC, 0.01 A
(Receiver only)
N.C. (Solid State Switch): 3.6 VDC, 0.01 A
N.C. (Mechanical Switch): 3.6 VDC, 0.01 A
Opens when cover, main unit
or back box is removed.
Alarm: ON
Light receiving: OFF
Not Light receiving: OFF
Light receiving: Blinking or OFF
Power ON: ON
Power OFF: OFF
Voltage reduction: Blinking
-20°C - +60°C (-40°F - 140°F)
95 % (max.)
±90° Horizontal, ±10° Vertical
H х W х D mm (inch):
452 (17.9) x 83 (3.3) x 138 (5.4)
3300 g (Total weight of Transmitter +
Receiver, excluding accessories)
IP65
