2. Panel Descriptions

2-1. Front Panel

DC POWER 1 GENLOCK
DC POWER 2
FAN ALARM LTC IN
(1) (2)
No Name
1 Power switch
Unit status
2
indicator
SDI IN status
3
indicator
OPTION SLOT
4
status indicator
5 INITIALIZATION
All setting data will initialize. Back up before executing a reinitialization.
SDI IN
1 2 3 4 5 6 7 8 9 10
BY-PASS INSTALL
VIDEO VIDEO IN
AUDIO AUDIO IN
(3)
Used to turn the unit ON / OFF.
DC Lit green
POWER
Lit red
1/2
Lit green
FAN
ALARM
Lit red
Lit green
GENLOCK
Unlit
Lit green
LTC IN
Unlit
Lit green
BY-PASS
Unlit
Lit green
VIDEO
Unlit
Lit green
AUDIO
Unlit
Lit green
INSTALL
Unlit
Lit green
VIDEO IN
Unlit
Lit green
AUDIO IN
Unlit
Used to reinitialize the unit. Read the WARNING below before
proceding. To reinitialize the unit, turn the unit on while holding down
the INITIALIZATION button.
WARNING
10
OPTION SLOT
A B C D
INITIALIZATION
(4) (5)
Description
Power supply is normal.
A power failure has occurred.
All fans are operating normally.
One or more fans have failed.
Genlock signal input is present.
No genlock signal input is present.
LTC input is present.
No LTC input is present.
Input signal is being bypassed.
No signal is being bypassed.
Video signal input is present.
No video signal input is present.
Embedded audio signal is present.
No embedded audio signal is present.
One or more option cards are found and
recognized in option slots A to D.
No option card is installed or recognized.
Video signal input(s) is/are present in option
slot(s).
No video signal input in option slots.
Audio signal input(s) is/are present in option
slot(s).
No audio signal input in option slots.
FA- 1010
FRAME SYNCHRONIZER
