MFR-16MADIPO/16AESPO
st
Installation Guide
1
1. Overview
MFR-16MADIPO or MFR-16AESPO is an output expansion card for MFR main units.
◆ Output Card Installation Slots (MFR-5000)
Output Card
Max. Number
MFR-16MADIPO
8
MFR-16AESPO
8
◆ Output Card Installation Slots (MFR-8000)
Output Card
Max. Number
MFR-16MADIPO
8
MFR-16AESPO
8
Edition
2. Output Card Installation Slots
◆ MFR-5000
Slot
09 - 16
09 - 16
Slot
09 - 16
09 - 16
◆ MFR-8000
16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17
What is in the Box
Output card (MFR-16MADIPO/16AESPO)
Installation Guide (This sheet)
Rear panel (supplied with each MFR-16MADIPO/16AESPO card)
MFR-16MADIPO
MFR-16AESPO
Install into slots:
No.09 - 16
← Slot No
16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01
← Slot No
MFR-16MADIPO
MFR-16AESPO
Install into slots:
No.09 - 16
← Slot No
