  • Page 2 1. Prior to Starting 1-1. Unpacking HVS-2000EX cards and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing list below. ITEM REMARKS HVS-2000EX Function Expansion Card Installation guide (This guide) 1-2. About HVS-2000EX The HVS-2000EX is a function expansion card specifically designed for the HVS-2000.
  • Page 3 ALARM Screw Screw POWER 3 ALARM (2) Insert the HVS-2000EX card into the top free slot. HVS-2000EX card (3) Tighten the two screws at both sides to secure the front panel to the chassis. HVS-2000 DIGITAL VIDEO SWITCHER POWER 1...
  • Page 4 HVS-2000EX is properly displayed in the menu. ① Open [STATUS > OPTION] menu. ② Check that "INSTALLED" is displayed for HVS-2000EX. (See the figure below.) (2) Verify that the HVS-2000EX card functions properly. Check that advanced chromakey channels are available.
