DK-45 User Manual
DESCRIPTION
The DK-45 is a high-tech product providing control and
protection of screw or piston type air compressors
driven by electric motors.
The controller incorporates all functions needed in a
compressor control panel. Thus no additional modules
are necessary resulting in lower panel cost.
The "early start" function analyzes the air consumption
trend and runs the compressor so that the pressure
never falls below the low limit.
The controller is directly supplied from the 230/400V
utility network. It provides fail contact and sensor
supplies internally, removing the need for a supply
transformer in the panel.
Utility mains voltages and frequency can be read on
the controller. It offers low/high voltage and phase
order protections.
The 2.9" wide, 128x64 pixels graphical screen displays
values in bigger size and with graphic support.
The logic level Modbus RTU communication port of the
controller allows computer connection providing
monitoring and program parameter adjusting.
Optically isolated digital inputs feature noise filtering
allowing fault-free operation in electrically noisy
environments.
The controller provides 5 relay outputs rated at 5
Amps.
The controller configuration may be done through the
front panel or using the free PC software. The PC
software is available for free download at
manufacturer's website.
It is possible to monitor and record the controller using
the free RAINBOW+ software.
V1.0 (22.09.2016)
DK-45
COMPRESSOR
CONTROLLER
FEATURES
● Graphical LCD screen: 128x64 pixels, 2.9"
● Automatic operation from output pressure
● Voltage protection relay function
● Phase order protection relay function
● Analog speed control output
● Multiple compressor support
● Flexible motor hours calculation algorithm
● Early start function preventing pressure drop
● Dryer control function
● History records
● 5 independent service counters
● Supports various topologies
● Displays utility mains voltages
● No external transformer needed
● Star / Delta start-up
● Load solenoid control
● 5 programmable relay outputs
● Optically isolated, programmable digital inputs
● 2 pressure sensor inputs
● 2 temperature sensor inputs
● Adjustable sensor characteristics
● Logic level serial port
● MODBUS-RTU communications
● Password protected front panel programming
● Low panel depth, easy installation
● Wide operating temperature range
● Sealed front panel (IP65 with gasket)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DK-45 and is the answer not in the manual?

Questions and answers

Summary of Contents for Datakom DK-45

  • Page 1 CONTROLLER DESCRIPTION FEATURES ● Graphical LCD screen: 128x64 pixels, 2.9” The DK-45 is a high-tech product providing control and protection of screw or piston type air compressors ● Automatic operation from output pressure driven by electric motors. ● Voltage protection relay function The controller incorporates all functions needed in a ●...
  • Page 2 DK-45 family controllers. Follow carefully advices given in the document. These are often good practices for the installation of compressor controllers which reduce future issues. For all technical queries please contact Datakom at below e-mail address: technical.support@datakom.com.tr QUERRIES If additional information to this manual is required, please contact the manufacturer directly at below e- mail address: technical.support@datakom.com.tr...
  • Page 3 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) SAFETY NOTICE Failure to follow below instructions will result in death or serious injury  Electrical equipment should be installed only by qualified specialist. No responsibility is assured by the manufacturer or any of its subsidiaries for any consequences resulting from the non-compliance to these instructions.
  • Page 4: Table Of Contents

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) TABLE OF CONTENTS 1. INSTALLATION INSTRUCTIONS 1.1. FRONT AND REAR PANELS 1.2. MECHANICAL INSTALLATION 1.3. ELECTRICAL INSTALLATION 1.4. CONNECTION DIAGRAM 2. PUSHBUTTON FUNCTIONS 3. SCREEN SCROLLING 4. MODES OF OPERATION 5. ALARMS AND WARNINGS 5.1. SERVICE ALARM OPTIONS 5.2.
  • Page 5: Installation Instructions

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 1.1 INSTALLATION INSTRUCTIONS Before installation:  Read the user manual carefully, determine the correct connection diagram.  Remove all connectors and mounting brackets from the controller, then pass the controller through the mounting opening. ...
  • Page 6: Front And Rear Panels

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 1.1. FRONT AND REAR PANELS 1.2. MECHANICAL INSTALLATION WALL min 60mm 40mm Panel Cutout Dimensions Required Panel Depth - 6 -...
  • Page 7: Electrical Installation

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 1.3. ELECTRICAL INSTALLATION Do not install the controller close to high electromagnetic noise emitting devices like contactors, high current busbars, switchmode power supplies and the like. Although the controller is protected against electromagnetic disturbance, excessive disturbance can affect the operation, measurement precision and data communication quality.
  • Page 8: Connection Diagram

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 1.4. CONNECTION DIAGRAM - 8 -...
  • Page 9: Pushbutton Functions

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 2. PUSHBUTTON FUNCTIONS Three pushbuttons on the front panel allow access to programming and measuring screens. BUTTON DESCRIPTION FUNCTION Displays the next parameter. MENU Reset alarms. PROGRAMMING: Save the adjusted parameter. Reset alarms and run the compressor.
  • Page 10: Screen Scrolling

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 3. SCREEN SCROLLING When the controller powers-on, the top part of the display will show (P1) the first pressure sensor (or first pressure switch). The pressure unit may be displayed as PSI or Bar following program parameter setting.
  • Page 11 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Phase-to-Neutral voltage screen Phase-to-Phase voltage screen Run Hours Screen Service Timers Screen This screen shows remaining time to services A,B, C, D and E in hours. Service timers operate on a decremental basis. Service bars are emptied with relation to timer values.
  • Page 12 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Information Screen If the E.47 Motor Control PWM Signal is enabled, then instead of start/stop pressures, this screen will show the E.48 Motor Control PWM Set Pressure (DRVR SET PRS) parameter. Alarm history Screen Alarm history will be described in detail in chapter 6.6.
  • Page 13 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Below is the description of some abbreviations displayed on the screen: ABBREVIATION DESCRIPTION First pressure sensor value or first pressure switch position Second pressure sensor value or second pressure switch position P2-P1 differential pressure (Delta pressure)
  • Page 14 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Below is the description of some icons displayed on the screen: ICON DESCRIPTION OFF, disabled, not-OK Remote Start Reset, cancel, disable Enabled, adjusted, action complete, OK Enter / change password Motor PTC Pressure-2 in Separator filter...
  • Page 15: Modes Of Operation

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 4. MODES OF OPERATION Selecting the mode of operation: When powered-up, the device turns-on all lights during 3 seconds for verification. Then it goes into STOP mode and the STOP led turns on. The compressor may be run with the REMOTE START signal (...
  • Page 16 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Start-up procedure: If utility mains voltages and frequency is between set limits and the phase order is correct, the the LINE led will turn on. The compressor can run only when the LINE led is on. Otherwise it cannot be run by any means.
  • Page 17: Alarms And Warnings

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 5. ALARMS AND WARNINGS Abnormal conditions of a compressor are divided into 3 categories, being WARNINGS, ALARMS and SERVICE REQUESTS. Warnings are the lowest priority fault conditions and result only in visual warnings. Alarms are highest level fault conditions and cause the compressor to stop immediately, the alarm relay to operate (if enabled) and the controller give visual warning.
  • Page 18: Service Alarm Options

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 5.1. SERVICE ALARM OPTIONS Following the selection of the program parameter F.02 Stop Service Request, the expiration of a service timer may simply cause a visual warning and the activation of the alarm relay, or it may also cause below...
  • Page 19: List Of Fault Codes

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 5.2. LIST OF FAULT CODES ICON CODE DESCRIPTION FAULT LEVEL Pressure Safety Switch Open ALARM ALARM 01 High Pressure ALARM ALARM 02 Pressure sensor failure ALARM ALARM 03 High temperature Alarm ALARM ALARM 04 High Temperature Warning...
  • Page 20 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) ICON CODE DESCRIPTION FAULT LEVEL Phase order failure ALARM ALARM 15 Air filter clogged WARNING ALARM 16 Max starts per hour exceeded WARNING ALARM 17 Emergency stop ALARM ALARM 18 Internal failure WARNING ALARM 19...
  • Page 21 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) ICON CODE DESCRIPTION FAULT LEVEL ALARM 30 WARNING Input expected ALARM 50 WARNING Data line failure (multiple control) Service period A exceeded SERVICE SERVİS A Service period B exceeded SERVICE SERVİS B Service period C exceeded SERVICE SERVİS C...
  • Page 22: Other Features

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6. OTHER FEATURES 6.1. RESETTING SERVICE COUNTERS Service counters can be reset only when the compressor is in STOP state. In order to reset service counters: - Hold pressed MENU and RUN pushbuttons during 3 seconds. If the HIGH LEVEL password is not entered in the last 90 minutes, then the controller will ask for password.
  • Page 23 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) - Press again the MENU pushbutton. The remaining hours to service A will be displayed. - In order to reset service A, hold the MENU button pressed during 3 seconds. (hours remaining to service B) icon and (reset) icon will be displayed.
  • Page 24: Modifying Motor Run Hours

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.2. MODIFYING MOTOR RUN HOURS Below are run hour counters of the device. MESSAGE DESCRIPTION Total motor run hours (on_LOAD + off_LOAD) RUN H. This counter increments while the motor is running. Total on_LOAD run hours (LOAD output active) LOAD H.
  • Page 25: Selection Of Motor Hours Counting Method

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.3. SELECTION OF MOTOR HOURS COUNTING METHOD The controller offers the possibility of counting motor hours with a variable coefficient depending on output air temperature. The usage of variable coefficient is selected with F.03 Motor Hours Calculation Method parameter. If this parameter is not activated, then all service and motor hour counters are calculated with a coefficient of 1.00, independent of the output air temperature.
  • Page 26: Connection Topologies

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.4. CONNECTION TOPOLOGIES The controller supports various utility mains connection topologies. The selection is made through C.04 Connection Topology parameter. Connection diagrams for various topologies are below: C.04 = 1 C.04 = 3 C.04 = 3 C.04 = 2...
  • Page 27: Preventing Pressure Loss

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.5. PREVENTING PRESSURE LOSS If the outputs pressure stays above E.05 Start Pressure during E.25 Unload Timer, then the controller will stop the motor. When the motor is at rest, if the pressure falls below E.05 Start Pressure then the motor will run again.
  • Page 28: Alarm History

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.6. ALARM HISTORY The controller keeps record of last 9 alarms in its alarm history list. The alarm history may be visualized on the screen or read through Modbus communication. Alarm history is kept in a non-volatile memory and is not affected by power failures.
  • Page 29: Dryer Function

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.7. DRYER FUNCTION If E.56 Dryer Delay Timer is adjusted to a value other than zero, the “STARTUP PROCEDURE” described in chapter 4 will be performed in a different manner. If the timer is not zero, then the MAIN relay output will be activated before the STAR relay and will stay active during E.56 Dryer Delay Timer.
  • Page 30: Motor Ptc Input

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 6.10. MOTOR PTC INPUT The secondary temperature sensor or a Motor PTC may be connected to the terminal 17 (TEMP.2/PTC) input of the controller. If a motor PTC sensor is connected, then E.16 Temp.2 Sensor parameter should be 0 and E.12 Motor PTC parameter should be 1.
  • Page 31: Multi-Compressor Operation

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 7. MULTI-COMPRESSOR OPERATION The multi-compressor mode is designed for cases where more than 1 compressor is needed to supply the necessary compressed air. In case of low air demand, the multi-compressor mode turns on only the necessary number of compressors, providing energy efficiency, cost control and equal aging of compressors.
  • Page 32: Digital Inputs

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 8. DIGITAL INPUTS The controller provides 4 user programmable digital inputs. Input characteristics are programmed with parameters D.02 to D.05. The input configuration consists on 3 pieces and the programmed value is the sum of these 3 pieces.
  • Page 33: Relay Outputs

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 9. RELAY OUTPUTS The unit provides 5 relay outputs with fully programmable functions. The factory set values of relay functions and related program parameters are shown in below table: RELAY # FACTORY SET PROGRAM #...
  • Page 34: Programming

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10. PROGRAMMING 10.1. ENTERING THE PROGRAMMING MODE Program menu can be selected only when the compressor is in STOP mode. The program menu is protected by a 2 level password system. Parameter set and password levels may differ following compressor manufacturers.
  • Page 35 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) - When inside a parameter group, the group name and icon will be displayed on top of screen. Below will come the code and name of the parameter. If the parameter has a unit, it will be displayed together with the parameter value.
  • Page 36 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Programlama konumundaki parametre grupları sırasıyla şunlardır:  A.ALARM HISTRY (Alarm history)  B.CONFIGURATION (Configurations)  C.ELECTRICAL (Electrical parameters)  D.INPUT-OUTPUT (Input-Output parameters)  E.COMPRESSOR (Compressor parameters)  F.MOTOR (Motor parameters)  G.PASSWORD (Change password) ...
  • Page 37: List Of Parameters

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2. LIST OF PARAMETERS Below is the list of all possible parameters. The description section gives first the parameter name in uppercase letters as it appears on the screen, then the description of it in lowercase letters.
  • Page 38 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2.3. ELECTRICAL PARAMETERS Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS VOLT.UNBALANCE % : % 0 ... 20 Voltage unbalance ratio C.01 0: disabled LOW VOLT. ALARM : 1: enabled Low voltage alarm enable If this parameter is set to 0 then the C.02...
  • Page 39 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS HIGH FREQ.ALARM: 50.0 ... 990.0 Hz 62.0 High frequency alarm limit C.11 DISPLAY FREQ : 0: no Display frequency 1: yes C.12 DISPLAY VOLT. L1 : 0: no...
  • Page 40 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2.4. INPUT-OUTPUT PARAMETERS Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS RELAY5 FUNCTION : 0 ... 12 (see chapter 9) D.01 INPUT-1 CONTROL : 0 ... 2047 Input_1 configuration Please see chapter 8 for details. D.02 INPUT-2 CONTROL : 0 ...2047...
  • Page 41 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2.5. COMPRESSOR PARAMETERS Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS 0: Analog sensor connected PRESS. CONTROL : Pressure sensor type 1: Pressure switch connected E.01 If this parameter is set to 1 then parameters E.02 ... E.06 will not be visible.
  • Page 42 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS 0: Not connected MOTOR PTC : 1: Connected Motor PTC connection If this sensor type is selected, when the sensor E.12 impedance is over 2000 ohms, the ALARM 09 Motor PTC High Temperature will occur.
  • Page 43 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS T2 AL WRN TIME : Temperature 2 1 ... 600 10 sec alarm/warning automatic E.20 reset delay TEMP.-2 OFFSET : 0 °C -10 ... +10 Temperature sensor 2 offset adjustment E.21...
  • Page 44 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS SERVICE D TIME : 0 ... 32767 10000 Service D period If this parameter is set to 0 then service D hours (Change oil) warning will not be given.
  • Page 45 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS 0: not connected PRES-2 SNSR.TYP : 1: Pressure switch connected Pressure 2 sensor type E.40 2: Analog sensor connected If this parameter is set to 1 then parameters E.41 ...
  • Page 46 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS PID I VALUE : %0.0 ... 99.9 PID control I gain E.50 PID D VALUE : %0.0 ... 99.9 % 5.0 PID control D gain E.51 PID I INVRS VAL : %0.0 ...
  • Page 47 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2.6. MOTOR PARAMETERS Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS MAX STRTS PER H : Maximum number of 6 ... 240 starts allowed in one F.01 hour STP.SRVC.RQUEST : 0: Warning only on service request...
  • Page 48 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 10.2.8. RETURN/SAVE TO FACTORY SETTINGS OR SAVED SETTINGS Factory ICON and No: DESCRIPTION ADJUSTMENT LIMITS 0: no action RETURN SAVE : 1: Return to restore point values Return to restore values/ return to factory settings H.01...
  • Page 49: Modbus Communications

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 11. MODBUS COMMUNICATIONS 11.1. DESCRIPTION The unit offers the possibility of MODBUS communication through its serial port. The serial port has 0/+5V logic levels.Using special adapters it is converted to RS-232 or RS-485 standards. The MODBUS properties of the unit are:...
  • Page 50 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Data reading The function 03 (read multiple registers) will be used for data reading. The MODBUS master will send a query. The answer will be one of the below: -A response containing the requested data -An exceptional response indicating a read error.
  • Page 51 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Data Writing (single register) The function 06 (write single register) and the function 16 (write multiple registers) are used for data writing. The MODBUS master will send a query containing data to be written. The answer will be one of the...
  • Page 52 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Data Writing (multiple register) The function 06 (write single register) and the function 16 (write multiple registers) are used for data writing. The MODBUS master will send a query containing data to be written. The answer will be one of the...
  • Page 53 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) CRC calculation Here is a procedure for generating a CRC: 1) Load a 16–bit register with FFFF hex (all 1’s). Call this the CRC register. 2) Exclusive OR the first 8–bit byte of the message (the function code byte) with the low–order byte of the 16–bit CRC register, putting the result in the CRC register.
  • Page 54: Modbus Register List

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 11.2. MODBUS REGISTER LIST CONTROLLER REGISTERS READ/ ADDR. NAME DESCRIPTION LENGTH DATA TYPE COEFF WRITE 40001 Frequency 16 BIT unsigned word 40002 Voltage phase L1 16 BIT unsigned word 40003 Voltage phase L2 16 BIT...
  • Page 55 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) CONTROLLER REGISTERS READ/ ADDR. NAME DESCRIPTION LENGTH DATA TYPE COEFF WRITE Current status of the motor 0: Compressor STOP mode 1: Motor in star run 2: Motor in delta (off_load) 40033 Motor status 16 BIT...
  • Page 56 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) CONTROLLER REGISTERS READ/ ADDR. NAME DESCRIPTION LENGTH DATA TYPE COEFF WRITE 40059 Flashing counter Flashing relay counter value 32 BIT unsigned dword 40060 Number of active flashing 40061 Active flashing relays 16 BIT unsigned word...
  • Page 57 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) PROGRAM PARAMETERS READ/ COEFF ADDR. NAME DESCRIPTION LENGTH DATA TYPE WRITE 40155 E.26 Explained in chapter 10.2 16 BIT unsigned word 40156 E.27 Explained in chapter 10.2 16 BIT unsigned word 40157 E.28 Explained in chapter 10.2...
  • Page 58 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) PROGRAM PARAMETERS READ/ COEFF ADDR. NAME DESCRIPTION LENGTH DATA TYPE WRITE 40196 B.05 Explained in chapter 10.2 16 BIT unsigned word 40197 B.06 Explained in chapter 10.2 16 BIT unsigned word 40198 C.19 Explained in chapter 10.2...
  • Page 59 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) SENSOR GRAPHICS 40385 Pressure Sensor Pressure sensor table 32*16 unsigned Graphic [32] (mA - Bar) word 40416 40417 Temperature Sensor Temperature sensor table 32*16 signed word (Ohm - °C) Graphic [32] 40448 40449 Motor PTC Sensor...
  • Page 60 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) COMMANDS 40769 C01 Reserved 16 BIT unsigned word Return to factory settings 40770 C02 16 BIT unsigned word (value = 0xAA55h) Reset counter 40771 C03 16 BIT unsigned word { value = Counter (1-8) }...
  • Page 61: Alarms, Warnings, Service Requests

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 11.3. ALARMS, WARNINGS, SERVICE REQUESTS The alarm record is 32 bytes long. Every bit shows the existency of a given alarm. BIT NO DESCRIPTION Low voltage High voltage Low frequency High frequency Fan motor high temperature...
  • Page 62 DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) Warning record is 16 bits long. Every bit shows the existency of a given warning. BIT NO DESCRIPTION Remote stop signal Remote start signal Adjusted parameter out of range High temperature warning Motor not stopped in last 1 hour...
  • Page 63: Declaration Of Conformity

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 12. DECLARATION OF CONFORMITY The unit conforms to the EU directives -2006/95/EC (low voltage) -2004/108/EC (electro-magnetic compatibility) Norms of reference: EN 61010 (safety requirements) EN 61326 (EMC requirements) The CE mark indicates that this product complies with the European requirements for safety, health environmental and customer protection.
  • Page 64: Technical Specifications

    DK-45 Kullanım Kılavuzu V1.0 (22.09.2016) 13. TECHNICAL SPECIFICATIONS Supply Voltage: 305 – 460 VAC (COMM-400V) 175 - 275VAC (COMM-230V) Supply Frequency: 50 - 60Hz nominal (± %10) Power Consumption: < 4 VA Measurement Inputs: Voltage: 20 - 520 V AC (Phase-Phase)
